Danfoss VLT Design Guide

4.2 Ordering Numbers
4.2.1 Ordering Numbers: Options and Accessories
NOTE
Options can be ordered as factory built-in options,
see ordering information
Type Description Ordering
no.
Miscellaneous hardware I
DC link
connector
Terminal block for DC link
connnection on A2/A3
130B1064
IP 21/4X top/
TYPE 1 kit
IP21/NEMA1 Top + bottom A2 130B1122
IP 21/4X top/
TYPE 1 kit
IP21/NEMA1 Top + bottom A3 130B1123
IP 21/4X top/
TYPE 1 kit
IP21/NEMA1 Top + bottom B3
130B1187
IP 21/4X top/
TYPE 1 kit
IP21/NEMA1 Top + bottom B4
130B1189
IP 21/4X top/
TYPE 1 kit
IP21/NEMA1 Top + bottom C3
130B1191
IP 21/4X top/
TYPE 1 kit
IP21/NEMA1 Top + bottom C4
130B1193
IP21/4X top IP21 Top Cover A2 130B1132
IP21/4X top IP21 Top Cover A3 130B1133
IP 21/4X top IP21 Top Cover B3 130B1188
IP 21/4X top IP21 Top Cover B4 130B1190
IP 21/4X top IP21 Top Cover C3 130B1192
IP 21/4X top IP21 Top Cover C4 130B1194
Panel Through
Mount Kit
Enclosure, frame size A5 130B1028
Panel Through
Mount Kit
Enclosure, frame size B1 130B1046
Panel Through
Mount Kit
Enclosure, frame size B2 130B1047
Panel Through
Mount Kit
Enclosure, frame size C1 130B1048
Panel Through
Mount Kit
Enclosure, frame size C2 130B1049
Type Description Ordering
no.
Miscellaneous hardware I
Terminal blocks Screw terminal blocks for replacing
spring loaded terminals
1 pc 10 pin 1 pc 6 pin and 1 pc 3
pin connectors 130B1116
Backplate A5 IP55/NEMA 12 130B1098
Backplate B1 IP21/IP55 / NEMA 12 130B3383
Backplate B2 IP21/IP55 / NEMA 12 130B3397
Backplate C1 IP21/IP55 / NEMA 12 130B3910
Backplate C2 IP21/IP55 / NEMA 12 130B3911
Backplate A5 IP66 130B3242
Backplate B1 IP66 130B3434
Backplate B2 IP66 130B3465
Backplate C1 IP66 130B3468
Backplate C2 IP66 130B3491
LCPs and kits
LCP 102 Graphical Local Control Panel
(GLCP)
130B1107
LCP cable Separate LCP cable, 3 m 175Z0929
LCP kit Panel mounting kit including
graphical LCP, fasteners, 3 m cable
and gasket
130B1113
LCP kit Panel mounting kit including
numerical LCP, fasteners and gasket
130B1114
LCP kit Panel mounting kit for all LCPs
including fasteners, 3 m cable and
gasket
130B1117
LCPækit Front mounting kit, IP55/IP66
enclosures, fasteners, 8 m cable and
gasket
130B1129
LCP kit Panel mounting kit for all LCPs
including fasteners and gasket -
without cable
130B1170
Table 4.3 Options and Accessories
How to Order
VLT
®
Refrigeration Drive Design Guide
MG16G102 - VLT
®
is a registered Danfoss trademark 53
4
4

Danfoss VLT Specifications

General

Frequency	50/60 Hz
Enclosure	IP20, IP21, IP55, IP66
Series	VLT
Control Technique	Flux Vector Control
Output Voltage	0-Vinput
Control Method	Fieldbus
Communication Interface	PROFIBUS, CANopen
Protection Features	Overload, Overvoltage, Undervoltage, Short Circuit, Ground Fault
Cooling Method	Liquid Cooled
Storage Temperature	-25°C to +70°C
Relative Humidity	5-95% non-condensing
Altitude	Up to 1000m (3280ft) without derating, up to 4000m (13120ft) with derating
Operating Temperature	-10°C to +50°C (14°F to 122°F)
