Description of choice:
Select the required control word protocol.
For further information about using the Metasys N2
Protocol see MG91CX and Modbus RTU see MG10SX.
570 Modbus parity and message framing
(M.BUS PAR./FRAME)
Value:
(EVEN/1 STOPBIT)
[0]
(ODD/1 STOPBIT)
[1]
✭ (N O PARITY/1 STOPBIT)
[2]
(NO PARITY/2 STOPBIT)
[3]
Function:
This parame ter sets up the drive’sModbusRTU
interface to communicate properly with the master
controller. The parity (EVEN, ODD, or NO PARITY) must
be set to match the setting of the master controller.
Description of choice:
Select the parity that matches the setting for the
Modbus master controller. Even or odd parity is
sometimes used to allow a transmitted word to be
checked for errors. Because Modbus RTU uses
the more efficient CRC (Cyclic Redundancy C heck)
method of checking for errors, parity checking is
seldom used in Modbus RTU networks.
571 Modbus communications timeout
(M.BUS COM.TIME.)
Value:
10 ms - 2000 ms
✭ 100 ms
Function:
This parameter determines the maximum amount
of t ime that the drive’s M odbus RTU will wait
between characters that are sent by the master
controller. When this amount of t ime expires, the
drive’s M odbus RTU interface will assume that it
has received the enti re message.
Description of choice:
Generally, the value of 100 ms is sufficient for Modbus
RTU networks, although some Modbus RTU networks
may operate on a timeout value as short as 35 ms.
If this value is set too short, the drive’s Modbus RTU
interface may miss a part of the message. Since the
CRC check will not be v alid, the drive will ignore the
message. The resulting retransmissions of messages
will slow communications on the network.
If this value is set too long, the drive will wait longer
than necessary to determine that the message is
completed. This w ill delay the drive’s response to the
message and possibly cause the master controller to
time out. The resulting retransmissions of messages
will slow communicat ions on the network.
580-582 Defined parameters
(DEFINED PNU’S)
Value:
Read only
Function:
The three parameters hold a list of all the parame ters
that are defined in the VLT 2800. It is possible to read
single elements of the list by using the corresponding
subindex. The subindexes start at 1 and follow
the order of the parameter numbers.
Each parameter holds up to 116 elements
(parameter numbers).
When a 0 is returned as parameter n umber the list ends.
✭ = factory setting. () = di splay text [] = value for use in communication via serial communicat ion port
