Danfoss VT2800 Series User Manual

VLT
®
2800 Series
All about VLT
2800
■ Technical data, mains supply 3 x 380 - 480 V
According to international standards Type 2805 2807 2811 2815 2822 2830
Output current I
INV.
[A] 1.7 2.1 3 .0 3.7 5.2 7.0
(3 x 380-480V) I
MAX
(60s) [A] 2.7 3.3 4.8 5.9 8.3 11.2
Output power (400 V) S
INV.
[KVA] 1.1 1.7 2.0 2.6 3.6 4.8
Typical shaft output P
M,N
[kW] 0.55 0.75 1.1 1.5 2.2 3.0
Typical shaft output P
M,N
[HP] 0.75 1.0 1 .5 2.0 3.0 4.0
Max. cable cross
section, motor
[mm
2
/AWG]
1)
4/10 4/10 4/10 4/10 4/10 4/10
Input current I
L,N
[A] 1.6 1.9 2 .6 3.2 4.7 6.1
(3 x 380-4 8 0 V) I
L,MAX
(60s)[A] 2.6 3.0 4 .2 5.1 7.5 9.8
Max. cable cross
section, power
[mm
2
/AWG]
1)
4/10 4/10 4/10 4/10 4/10 4/10
Max. pre-fuses IEC/UL
2)
[A] 20/20 20/20 20/20 20/20 20/20 20/20
Efficiency
3)
[%]96969696 96 96
Power loss at 10 0%
load
[W] 28 38 55 75 110 150
Weight [kg] 2.1 2.1 2.1 2.1 3.7 3.7
Enclosure
4
type IP 20 IP 20 IP 20 IP 20 IP 20 IP 20
According to international standards Type 2840 2855 2875 2880 2881 2882
Output current I
INV.
[A] 9.1 12 16 24 32.0 37.5
(3 x 380-480V) I
MAX
(60s) [A] 14.5 19.2 25.6 38.4 51.2 60.0
Output power ( 400 V) S
INV.
[KVA] 6.3 8.3 11.1 16.6 22.2 26.0
Typical shaft output P
M,N
[kW] 4.0 5.5 7.5 11.0 15.0 18.5
Typical shaft output P
M,N
[HP] 5.0 7.5 10.0 15.0 2 0.0 25.0
Max. cable cross
section, motor
[mm
2
/AWG]
1)
4/10 4/10 4/10 16/6 16/6 16/6
Input cu rren t I
L,N
[A] 8.1 10.6 14.9 24.0 3 2.0 37.5
(3 x 380-480 V) I
L,MAX
(60s) [ A] 13.0 17.0 23.8 38.4 51.2 60
Max. cable cross
section, power
[mm
2
/AWG]
1)
4/10 4/10 4/10 16/6 16/6 16/6
Max. pre-fuses IEC/UL
2)
[A] 20/20 25/25 25/25 50/50 50/50 50/50
Efficiency
3)
[%]969696 97 97 97
Power loss at 100%
load
[W] 200 275 372 412 562 693
Weight [kg] 3.7 6.0 6.0 18.5 1 8.5 18.5
Enclosure
4
type IP20 IP20 IP20 IP20/
NEMA 1
IP20/
NEMA 1
IP20/
NEMA 1
1. American Wire Gauge. Max. cable cross
section is the largest cab
le cross section that can
be attached to the terminals. Always observe
nati onal and local regulatio ns.
2. Type gG pre-fuses must
be used for installation
according to IEC rules. If you want to maintain
UL/cUL you must use pre-fuses of the type
Bussmann KTN-R 200 V
, KTS-R 500 V or Ferraz
Shawmut, type ATMR (max. 30A). The fuses
must be placed for protection in a circuit that is
capable of supply
ing a maximum of 100,000 amps
RMS ( symmetrical), 500 V maximum.
3. Measured using a 25 m screened/armoured
motor cable with a rated lo
ad and rated frequency.
4. IP20 is standard for VLT 2805-2875,
whereas NEMA 1 is an o p tion.
MG.28.E9.02 - VLT is a registered Danfoss trademark
151
