VLT
®
2800 Series
■ Technical data, mains supply 1 x 220 -
240 V/3 x 200-240V
According to . international
standards
Type 2803 2805 2807 2811 28 15 2822 2840
Output current I
INV.
[A] 2.2 3.2 4.2 6.0 6.8 9.6 16
(3 x 200-240V) I
MAX
(60s) [A] 3.5 5.1 6.7 9.6 10.8 15.3 25.6
Output power (230 V) S
INV.
[KVA] 0.9 1.3 1.7 2.4 2.7 3.8 6.4
Typical shaft output P
M,N
[kW] 0.37 0.55 0.75 1.1 1.5 2.2 3.7
Typical shaft output P
M,N
[HP] 0.5 0.75 1.0 1.5 2 .0 3.0 5.0
Max. cable cross
section, motor
[mm
2
/AWG]
1)
4/10 4/10 4/10 4/10 4/10 4/10 4/10
Input current I
L,N
[A] 5.9 8.3 10.6 14.5 15.2 - -
(1 x 220-240 V) I
L,MAX
(60s) [A] 9.4 13.3 16.7 23. 2 24.3 - -
Input current I
L,N
[A] 2.9 4.0 5.1 7.0 7.6 8.8 14.7
(3 x 200-240 V) I
L,MAX
(60s) [A] 4.6 6.4 8.2 11.2 12.2 14.1 23 .5
Max. cable cross
section, power
[mm
2
/AWG]
1)
4/10 4/10 4/10 4/10 4/10 4/10 4/10
Max. pre-fuses IEC/UL
2)
[A] 20/20 20/20 20/20 20/20 20/20 20/2 0 25/25
Efficiency
3)
[%]95959595959595
Power loss at 100%
load
[W]2435486994125231
Weight [kg] 2.0 2.0 2 .0 2.0 2.0 3,7 6.0
Enclosure
4
type IP 20 IP 20 IP 20 IP 20 IP 20 IP 20 IP 20
1. American Wire Gauge. Max. cable cross
section is the largest cable cross section that can
be attached to the terminals. Always observe
nati onal and local regulatio ns.
2. Type gG pre-fuses must be used for installation
according to IEC rules. If you want to maintain
UL/cUL you must use pre-fuses of the type
Bussmann KTN-R 200 V, KTS-R 500 V or Ferraz
Shawmut, type ATMR (max. 30A). The fuses
must be placed for protection in a circuit that is
capable of supplying a maximum of 100,000 amps
RMS ( symmetrical), 500 V maximum.
3. M easured using a 25 m screened/armoured
motor cab le with a rated load and rated f re quency.
4. IP20 is standard for VLT 2805-2875,
whereas N EMA 1 is an option.
MG.28.E9.02 - VLT is a registered Danfoss trademark
150
