VLT
®
2800 Series
Programming
■ Inputs and outputs
Digital inputs Term. no. 18
1
19
1
27 29 33
par. no. 302 303 304 305 307
Value:
No functio n (NO O PERATIO N ) [0] [0] [0] [0] ✭[0]
Reset (RESET) [1] [1] [1] [1] [1]
Coasting stop inverse (MOTOR COAST INVERSE) [2] [2] [2] [2] [2]
Reset an d co asting inverse (RESET AND COAST INV.) [3] [3 ] ✭[3] [3] [3]
Quick-stop inverse (QU ICK -STOP INVERSE) [4] [4] [4] [4] [4]
DC braking inverse (DC-BRAKE INVERSE) [5] [5] [5] [5] [5]
Stop inverse (STOP INVERSE) [6] [6] [6] [6] [6]
Start (START) ✭[7] [7] [7] [7] [7 ]
Pulse start (LATCHED START) [8] [8] [8] [8] [8]
Reversing (REVERSING) [9] ✭[9 ] [9] [9] [9]
Reversing and start (START REVERSING) [10] [10] [10] [10] [10]
Start clockwise (ENABLE FORWARD) [11] [11] [11] [11] [11]
Start anti-clockwise (ENABLE REVERSE) [12] [12] [12] [12] [12]
Jog (JOGGING) [13] [13] [13] ✭[13] [13]
Freeze reference (FREEZE REFERENCE) [14] [14] [14] [14] [14]
Freeze output frequency (FREEZE OUTPUT) [15] [15] [15] [15] [15]
Speed up (SPEED UP) [16] [16] [16] [16] [16]
Speed down (SPEED DOWN) [17] [17] [17] [17] [17]
Catch-up (CATCH-UP) [19] [19] [19] [19] [19]
Slow-down (SLOW-DOWN) [20] [20] [20] [20] [20]
Ramp 2 (RAMP 2) [21] [21] [21] [21] [21]
Preset ref, LSB (PRESET REF, LSB) [22] [22] [22] [22] [22]
Preset ref, MSB (PRESET REF, MSB) [23] [23] [23] [23] [23]
Preset reference on (PRESET REFERENCE ON) [24] [24] [24] [24] [24]
Thermistor (THERM ISTOR) [25] [25] [25] [25]
Precise stop, inverse (PRECISE STOP INV.) [26] [26]
Precise start/stop (PRECISE START/STOP) [27] [27]
Pulse reference (PULSE REFERENCE) [28]
Pulse feedback (PULSE F EEDBACK) [29]
Pulse input (PU L SE INPU T) [30]
Selection of Setup, lsb (SETUP SELECT LSB) [31] [31] [31] [31] [31]
Selection of Setup, msb (SETUP SELECT MSB) [32] [32] [32] [32] [32]
Reset and start (RESET AND START) [33] [33] [33] [33] [33]
Pulse counter start (PULSE COU NTER START) [34] [34]
1. All functions on terminal 18 and 19 are
controlled by an interrupter, which means that
the r ep etitive accuracy of the response time is
constant. Can be used for start/stop, setup switch
and especially for changing digital preset, i.e. to
obtain a reproducable stop point when using creep
speed. For further info rm ation see VLT 2800
Precise Stop Instruction, MI.28.CX.02.
✭ = factory setting. () = di splay text [] = value for use in communication via serial communicat ion port
MG.28.E9.02 - VLT is a registered Danfoss trademark
87
