VLT
®
2800 Series
• EN 55011: Emission
Limits and methods of measurement of
radio disturbance characteristics of industrial, scien-
tific and medical (ISM) high-frequency equipment.
Class 1A:
Equipment used in an industria l environme nt.
Class 1B:
Equipment used in areas with a public supply network
(residential, commerce and light industry).
■ EMC Immunity
In order to document immunity agains t electrical
interference, the following immunity tests have
been made on a system consisting of a frequency
converter, a screened/armoured control cable and a
control box with potentiometer, screened/armoured
motor cable, screened/armoured brake cable
and an LCP 2 with a cable.
The tests were performed in accordance with
thefollowingbasicstandards:
• EN 61000-4-4 (IEC 61000-4-4): Burst transients
Simulation of interference brought about by
switching with contactors, relays or similar d evices.
• EN 61000-4-5 (IEC 61000-4-5): Surge transients
Simulation of transients brought about e.g. by
lightning that stri kes near installations.
• EN 61000-4-2 (IEC 61000-4-2) :
Electrostatic discharges (ESD)
Simulation of electrostatic discharge s
from human beings.
• EN 61000-4-3(IEC 61000-4-3): Incoming electro-
magnetic field radiation, amplitude modulated.
Simulation of the effects of radar and ra-
dio broadcast devices as well as mobile
communication devices.
• VDE 0160 class W2 test pulse: Mains transients
Simulation of high-energy transients generated
by breaks in master fuses, connection to phase
advancer batteries and the like.
• EN 61000-4-6 (IEC 61000-4-
6): RF Common mode
Simulation of the effect from ra dio-trans-
mitting equipment connected to connect ion cables.
See following EMC immunity form.
Basic standard Burst
61000-4-4
Surge
61000-4-5
ESD
61000-4-2
Radiated
61000-4-3
Mains
distortion
VDE 0160
RF CM
voltage
2
61000-4-6
Acceptance
criterion
B B B A A
Port connection CM DM / CM Field DM CM
Line OK / OK OK
Motor OK
Control lines OK -/OK
1
OK
Relay OK -/OK OK
Profibus OK -/OK
1
OK
Signal interface
<3 m
OK
Enclosure OK OK
Standard bus OK -/OK
1
OK
Basic speci-
fications
Line 2kV/DCN 2kV/4kV 10 Vrms
Motor 10 Vrms
Control lines 2 kV / CCC 2kV/2
1
10 Vrms
Relay 2 kV / CCC 2kV/2
1
10 Vrms
Profibus 2 kV / CCC 2kV/2
1
10 Vrms
Signal interface
<3 m
2 kV / CCC
Enclosure 8kVAD
6kVCD
10 V/m
Standard bus 2 kV / CCC 2kV/2
1
10 Vrms
DM: Differential mode CM : Common mode
MG.28.E9.02 - VLT is a registered Danfoss trademark
138
