■ Parameter list with factory settings
PNU
#
Parameter
description
Factory setting 4-setup Conv.
index
Data
type
001 Language English No 0 5
002 Local/remote operat ion Remote-controlled Yes 0 5
003 Local reference 000,000.000 Yes -3 4
004 Activ e Setup Setup 1 No 0 5
005 Programming Setup Active Setup No 0 5
006 Setup copying No co p ying No 0 5
007 LCP copy No copying No 0 5
008 Display scaling 1.00 Yes -2 6
009 Large display readout Frequency [Hz] Yes 0 5
010 Small display line 1.1 Reference [%] Yes 0 5
011 Small display line 1.2 Motor current [A] Yes 0 5
012 Small display line 1.3 Power [kW] Yes 0 5
013 Loc al control Remote control
as par. 100
Yes 0 5
014 Local stop/reset Active Yes 0 5
015 Local jog Not act ive Yes 0 5
016 Local reversing Not active Yes 0 5
017 Local reset of trip Active Yes 0 5
018 Da ta c hange loc k Not locked Yes 0 5
019 Operating status at
power up
Forced stop,
use saved ref.
Yes 0 5
020 Lock for Hand mode Active No 0 5
024 User-defined Quick Menu Not active No 0 5
025 Quick Menu Setup 000 No 0 6
4-Setup:
’Yes’ means that the parameter can be programmed
individually in each of the fo u r Setups, i.e. one single
parameter can have four different data values. ’No’
means that the data value will be the same in all Setu
ps.
C
onversion index:
This number refers to a conversion figure to be used
when writing or reading via serial communication
with a frequency converter.
See Data ch aracter in Serial communication
in the Design Guide.
D
ata type:
Data type shows the type and length of the telegram.
Data type Description
3 Integer 16
4 Integer 32
5 Unsigned 8
6 Unsigned 1 6
7 Unsigned 3 2
9Textstring
MG.28.E9.02 - VLT is a registered Danfoss trademark
