Danfoss VZH Series Application Guidelines

Application guidelines
14 FRCC.PC.023.A7.22
Single compressorsTechnical specications
Capacity at EN12900 rating conditions - High pressure ratio - VZH088AH - VZH117AH - VZH170AH
Models
rpm
Freq (Hz)
To -13 -10 0 10 20 30 40 50 59
Tc Qo Qo Qo Qo Qo Qo Qo Qo Qo
VZH088AG
1500 rpm
25
70 - - 19900 25000 31100 38200 46500 - -
90 - - 17600 22500 28200 34800 42400 51100 60000
110 - - 15200 19600 24800 30800 37600 45400 53300
130 - - - - 20700 25800 31700 38500 45300
140 - - - - - 22900 28300 34400 40600
145 - - - - - - - - -
3600 rpm
60
70 37800 40500 50700 63000 77800 95200 115500 - -
90 32400 34900 44500 55900 69500 85400 104000 125500 147500
110 - - 38600 48800 61000 75200 91700 110900 130600
130 - - - - 51400 63600 77900 94500 111600
140 - - - - - 57100 70100 85400 101100
145 - - - - - - 61700 75500 89800
6000 rpm
100
70 - - 82900 103100 127300 155900 189500 - -
90 - - 74100 92900 115300 141600 172300 207800 244100
110 - - 65100 82000 101900 125300 152600 184200 216700
130 - - - - 86300 106200 129500 156600 184600
140 - - - - - 95300 116300 141000 166500
145 - - - - - - - - -
VZH117AG
1500 rpm
25
70 - - 26700 33600 41700 51300 62400 - -
90 - - 23700 30200 37800 46700 56900 68600 80500
110 - - 20300 26400 33300 41300 50500 60900 71500
130 - - - - 27700 34700 42600 51600 60800
140 - - - - - 30700 38000 46200 54600
145 - - - - - - - - -
3600 rpm
60
70 50800 54400 68000 84600 104400 127800 155000 - -
90 43500 46900 59700 75100 93300 114700 139600 168500 198000
110 - - 51800 65600 81800 100900 123100 148900 175300
130 - - - - 69000 85400 104500 126800 149900
140 - - - - - 76700 94100 114600 135800
145 - - - - - - 82900 101300 120600
6000 rpm
100
70 - - 111300 138400 170900 209300 254300 - -
90 - - 99400 124700 154700 190100 231300 278900 327700
110 - - 87400 110000 136800 168200 204900 247300 290800
130 - - - - 115900 142600 173800 210200 247700
140 - - - - - 127900 156200 189200 223500
145 - - - - - - - - -
VZH170AG
1500 rpm
25
70 - - 41100 51000 62900 76900 93200 - -
90 - - 36000 45300 56300 69300 84400 101800 119600
110 - - 30400 38700 48600 60100 73600 89200 105100
130 - - - - 39400 49300 60800 74100 87900
140 - - - - - 43200 53500 65700 78300
145 - - - - - - - - -
3600 rpm
60
70 77000 81800 100500 123600 151700 185300 224900 - -
90 67000 71600 89400 111000 136900 167800 204200 246600 290300
110 - - 78600 97900 121000 148400 180700 218400 257400
130 - - - - 102300 125400 152900 185200 218800
140 - - - - - 112200 137000 166200 196900
145 - - - - - - 119400 145500 173100
6000 rpm
100
70 - - 165700 205700 254000 311200 378300 - -
90 - - 145700 182800 227000 279000 339800 410200 482400
110 - - 128700 162100 201500 247700 301500 363800 427800
130 - - - - 173200 212800 259000 312500 367700
140 - - - - - 192700 234800 283600 334200
145 - - - - - - - - -
To: Evaporating temperature in °F Superheat = 10 K Presented data are for models with motor voltage code G
Tc: Condensing temperature in °F Subcooling = 0 K
Qo: Cooling capacity in Btu Pe: Power input in kW
