Danfoss VZH Series Application Guidelines

Application guidelines
15FRCC.PC.023.A7.22
Single compressorsTechnical specications
Capacity at ARI rating conditions - High pressure ratio - VZH088AH - VZH117AH - VZH170AH
Models
rpm
Freq (Hz)
To -13 -10 0 10 20 30 40 50 59
Tc Qo Qo Qo Qo Qo Qo Qo Qo Qo
VZH088AG
1500 rpm
25
70 - - 21300 26700 33100 40700 49500 - -
90 - - 19100 24300 30400 37500 45700 55000 64500
110 - - 16700 21600 27200 33700 41100 49600 58100
130 - - - - 23300 29100 35700 43100 50700
140 - - - - - 26400 32500 39500 46600
145 - - - - - - - - -
3600 rpm
60
70 40500 43300 54200 67300 83000 101400 123000 - -
90 35100 37800 48100 60400 75000 92100 112000 135000 158600
110 - - 42400 53600 66800 82300 100300 121200 142600
130 - - - - 58000 71600 87500 106000 125100
140 - - - - - 65800 80700 97900 115900
145 - - - - - - 74000 90200 107100
6000 rpm
100
70 - - 88600 110100 135800 166200 201800 - -
90 - - 80100 100300 124300 152600 185500 223500 262400
110 - - 71600 90000 111800 137300 167000 201300 236500
130 - - - - 97300 119500 145500 175600 206700
140 - - - - - 109800 133800 161700 190700
145 - - - - - - - - -
VZH117AG
1500 rpm
25
70 - - 28600 35800 44500 54700 66500 - -
90 - - 25600 32600 40800 50300 61300 73800 86500
110 - - 22400 29000 36500 45300 55200 66600 78000
130 - - - - 31300 39000 47900 57900 68100
140 - - - - - 35400 43700 53000 62500
145 - - - - - - - - -
3600 rpm
60
70 54300 58200 72700 90300 111400 136200 165100 - -
90 47100 50700 64600 81100 100600 123600 150300 181200 212800
110 - - 57000 72000 89700 110500 134700 162700 191400
130 - - - - 77800 96100 117400 142300 167900
140 - - - - - 88400 108300 131500 155500
145 - - - - - - 99300 121000 143700
6000 rpm
100
70 - - 119000 147700 182300 223100 270800 - -
90 - - 107500 134600 166900 204800 249000 300000 352200
110 - - 96100 120800 150000 184300 224100 270200 317400
130 - - - - 130700 160500 195300 235800 277500
140 - - - - - 147400 179600 217100 256000
145 - - - - - - - - -
VZH170AG
1500 rpm
25
70 - - 43900 54500 67100 82000 99300 - -
90 - - 38900 48900 60800 74700 90800 109500 128600
110 - - 33400 42500 53300 65900 80500 97400 114700
130 - - - - 44500 55400 68300 83100 98500
140 - - - - - 49700 61500 75400 89700
145 - - - - - - - - -
3600 rpm
60
70 82400 87500 107400 132000 161800 197500 239500 - -
90 72500 77500 96700 119900 147700 180900 219800 265200 312000
110 - - 86400 107500 132700 162500 197600 238600 281000
130 - - - - 115300 141200 171800 207700 245100
140 - - - - - 129300 157500 190800 225600
145 - - - - - - 143100 173800 206300
6000 rpm
100
70 - - 177000 219700 270900 331700 402900 - -
90 - - 157600 197500 244900 300700 365800 441200 518500
110 - - 141500 178100 221000 271200 329800 397400 466900
130 - - - - 195300 239500 290900 350500 411900
140 - - - - - 222100 269900 325500 382900
145 - - - - - - - - -
To: Evaporating temperature in °F Superheat = 11.1 K Presented data are for models with motor voltage code G
Tc: Condensing temperature in °F Subcooling = 8.3 K
Qo: Cooling capacity in Btu Pe: Power input in kW
Subject to change without prior notice.
