Danfoss VZH Series Application Guidelines

Application guidelines
16 FRCC.PC.023.A7.22
Single compressorsTechnical specications
Capacity at EN12900 rating conditions - Low pressure ratio - VZH088BJ - VZH117BJ - VZH170BJ
Models
rpm
Freq (Hz)
Te -13 -10 0 10 20 30 40 50 59
Tc Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe
VZH088BJ
1500
25
70 - - - - 22100 1.84 27200 1.74 33300 1.65 40300 1.58 48500 1.54 - - - -
90 - - - - 18500 2.47 23300 2.39 28900 2.30 35400 2.22 42900 2.14 51500 2.08 60400 2.03
110 - - - - - - 19400 3.16 24400 3.11 30300 3.04 37100 2.96 45000 2.88 53100 2.80
130 - - - - - - - - - - 24900 4.13 31000 4.08 38100 4.01 45300 3.94
140 - - - - - - - - - - - - 27800 4.79 34400 4.74 41200 4.67
145 - - - - - - - - - - - - - - - - - -
3600
60
70 37000 4.64 39700 4.64 50000 4.59 62500 4.48 77500 4.36 95100 4.26 115600 4.24 - - - -
90 32000 5.83 34500 5.87 44200 5.91 55800 5.85 69500 5.72 85600 5.57 104200 5.44 125600 5.38 147500 5.41
110 - - - - - - 48800 7.50 61100 7.43 75500 7.29 92100 7.13 111200 6.98 130600 6.89
130 - - - - - - - - - - 63800 9.48 78200 9.34 94800 9.17 111700 9.02
140 - - - - - - - - - - - - 70200 10.66 85500 10.51 101100 10.35
145 - - - - - - - - - - - - 66000 11.38 80500 11.24 95500 11.08
6000
100
70 - - - - 81700 7.98 101200 7.94 124700 7.89 152500 7.92 185000 8.12 - - - -
90 - - - - 74000 10.39 92500 10.42 114600 10.32 140600 10.20 170800 10.14 205800 10.23 241700 10.53
110 - - - - - - 81400 13.10 101200 13.10 124400 12.95 151600 12.76 183000 12.62 215300 12.60
130 - - - - - - - - - - 104000 16.07 127100 15.88 154100 15.63 182100 15.43
140 - - - - - - - - - - - - 112900 17.59 137400 17.34 162800 17.08
145 - - - - - - - - - - - - - - - - - -
VZH117BJ
1500
25
70 - - - - 29600 2.42 36600 2.29 44700 2.17 54100 2.08 65100 2.02 - - - -
90 - - - - 24900 3.25 31300 3.14 38800 3.02 47500 2.91 57600 2.81 69200 2.73 81100 2.67
110 - - - - - - 26000 4.15 32800 4.08 40700 3.99 49900 3.88 60400 3.78 71300 3.68
130 - - - - - - - - - - 33500 5.43 41600 5.36 51100 5.27 60800 5.17
140 - - - - - - - - - - - - 37300 6.29 46100 6.22 55300 6.13
145 - - - - - - - - - - - - - - - - - -
3600
60
70 49700 6.09 53300 6.10 67100 6.03 83900 5.88 104000 5.72 127600 5.60 155200 5.57 - - - -
90 42900 7.66 46400 7.71 59300 7.76 74900 7.68 93300 7.51 114800 7.32 139900 7.15 168600 7.06 198000 7.10
110 - - - - - - 65500 9.84 82100 9.76 101300 9.58 123600 9.36 149200 9.16 175300 9.04
130 - - - - - - - - - - 85600 12.45 104900 12.27 127200 12.05 149900 11.85
140 - - - - - - - - - - - - 94300 14.00 114800 13.80 135700 13.59
145 - - - - - - - - - - - - 88500 14.94 108100 14.76 128200 14.55
6000
100
70 - - - - 109700 10.48 135900 10.43 167400 10.37 204600 10.41 248300 10.67 - - - -
90 - - - - 99300 13.64 124200 13.68 153800 13.56 188700 13.40 229300 13.32 276300 13.44 324400 13.82
110 - - - - - - 109200 17.21 135800 17.20 167000 17.01 203500 16.76 245700 16.57 289000 16.55
130 - - - - - - - - - - 139600 21.10 170700 20.86 206900 20.53 244400 20.26
140 - - - - - - - - - - - - 151600 23.10 184400 22.77 218500 22.44
145 - - - - - - - - - - - - - - - - - -
VZH170BJ
1500
25
70 - - - - 42200 3.30 51900 3.15 63400 2.99 77000 2.81 92800 2.61 - - - -
90 - - - - 36100 4.57 45200 4.42 56000 4.28 68600 4.13 83300 3.96 100300 3.77 117800 3.57
110 - - - - - - 38300 5.90 48000 5.76 59500 5.64 72900 5.52 88400 5.38 104400 5.24
130 - - - - - - - - -
- 49200 7.56 61100 7.48 74900 7.40 89100 7.33
140 - - - - - - - - - - - - 54500 8.67 67400 8.63 80800 8.59
145 - - - - - - - - - - - - - - - - - -
3600
60
70 71600 8.72 76900 8.67 97100 8.49 121600 8.30 151000 8.07 185900 7.78 226800 7.40 - - - -
90 62400 11.09 67400 11.05 86100 10.91 108700 10.77 135600 10.62 167400 10.43 204800 10.17 248200 9.83 293000 9.43
110 - - - - - - 94700 13.77 118600 13.67 146800 13.54 180000 13.38 218700 13.15 258800 12.87
130 - - - - - - - - - - 123500 17.48 151900 17.37 185400 17.22 220300 17.03
140 - - - - - - - - - - - - 136500 19.77 167200 19.65 199300 19.50
145 - - - - - - - - - - - - 128400 21.10 157600 20.99 188300 20.85
6000
100
70 - - - - 161800 15.35 202200 15.41 250400 15.25 307400 14.78 374200 13.94 - - - -
90 - - - - 144300 18.92 182000 19.17 226900 19.30 279800 19.22 341600 18.86 413300 18.15 487200 17.15
110 - - - - - - 159300 23.79 199600 24.03 247200 24.17 303000 24.12 367900 23.83 434800 23.29
130 - - - - - - - - - - 209000 30.26 257500 30.36 314400 30.31 373500 30.07
140 - - - - - - - - - - - - 232000 34.04 284400 34.05 339200 33.91
145 - - - - - - - - - - - - - - - - - -
To: Evaporating temperature in °F Superheat = 10 K Presented data are for models with motor voltage code J
Tc: Condensing temperature in °F Subcooling = 0 K
Qo: Cooling capacity in Btu Pe: Power input in kW
