Danfoss VZH Series Application Guidelines

Application guidelines
18 FRCC.PC.023.A7.22
Single compressorsTechnical specications
Capacity at EN12900 rating conditions - Low pressure ratio - VZH088BG - VZH117BG - VZH170BG
Models
rpm
Freq (Hz)
To -13 -10 0 10 20 30 40 50 59
Tc Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe
VZH088BG
1500 rpm
25
70 - - - - 22200 1.81 27400 1.71 33500 1.62 40600 1.55 48900 1.51 - - - -
90 - - - - 18700 2.43 23500 2.35 29100 2.26 35600 2.18 43200 2.10 51900 2.04 60900 2.00
110 - - - - - - 19500 3.10 24600 3.05 30500 2.98 37400 2.91 45400 2.82 53500 2.75
130 - - - - - - - - - - 25100 4.06 31300 4.01 38400 3.94 45700 3.87
140 - - - - - - - - - - - - 28000 4.71 34600 4.65 41500 4.59
145 - - - - - - - - - - - - - - - - - -
3600 rpm
60
70 37300 4.56 40000 4.56 50400 4.51 63000 4.40 78100 4.28 95800 4.19 116500 4.16 - - - -
90 32200 5.73 34800 5.77 44500 5.81 56200 5.74 70000 5.62 86200 5.47 105000 5.35 126600 5.28 148600 5.31
110 - - - - - - 49200 7.36 61600 7.30 76000 7.16 92800 7.00 112000 6.85 131600 6.76
130 - - - - - - - - - - 64300 9.31 78800 9.18 95500 9.01 112500 8.86
140 - - - - - - - - - - - - 70800 10.47 86100 10.32 101900 10.17
145 - - - - - - - - - - - - 66500 11.18 81100 11.04 96200 10.88
6000 rpm
100
70 - - - - 82400 7.84 102000 7.80 125600 7.75 153600 7.78 186400 7.98 - - - -
90 - - - - 74500 10.20 93200 10.23 115500 10.14 141600 10.02 172100 9.96 207400 10.05 243500 10.34
110 - - - - - - 82000 12.87 101900 12.87 125400 12.72 152700 12.54 184400 12.39 216900 12.38
130 - - - - - - - - - - 104800 15.78 128100 15.60 155300 15.35 183400 15.15
140 - - - - - - - - - - - - 113800 17.28 138400 17.03 164000 16.78
145 - - - - - - - - - - - - - - - - - -
VZH117BG
1500 rpm
70 - - - - 29800 2.38 36800 2.25 45000 2.13 54500 2.04 65600 1.98 - - - -
90 - - - - 25100 3.19 31500 3.08 39100 2.97 47800 2.86 58000 2.76 69700 2.68 81700 2.62
110 - - - - - - 26200 4.08 33000 4.01 41000 3.92 50200 3.82 60900 3.71 71800 3.61
130 - - - - - - - - - - 33700 5.33 41900 5.27 51500 5.18 61300 5.08
140 - - - - - - - - - - - - 37500 6.18 46500 6.11 55700 6.02
145 - - - - - - - - - - - - - - - - - -
3600 rpm
70 50100 5.99 53700 5.99 67600 5.92 84500 5.78 104800 5.62 128600 5.50 156400 5.47 - - - -
90 43300 7.52 46700 7.57 59800 7.62 75400 7.54 94000 7.38 115700 7.19 140900 7.02 169900 6.94 199500 6.97
110 - - - - - - 66000 9.67 82700 9.59 102100 9.41 124500 9.20 150300 9.00 176700 8.88
130 - - - - - - - - - - 86300 12.23 105700 12.05 128100 11.83 151100 11.64
140 - - - - - - - - - - - - 95000 13.76 115600 13.56 136700 13.35
145 - - - - - - - - - - - - 89200 14.68 108900 14.50 129100 14.30
6000 rpm
70 - - - - 110500 10.29 136900 10.25 168600 10.18 206200 10.22 250200 10.48 - - - -
90 - - - - 100000 13.40 125100 13.44 155000 13.32 190100 13.16 231000 13.08 278400 13.20 326800 13.58
110 - - - - - - 110000 16.90 136800 16.90 168300 16.71 205000 16.46 247500 16.28 291200 16.26
130 - - - - - - - - - - 140600 20.73 172000 20.49 208500 20.17 246200 19.90
140 - - - - - - - - - - - - 152700 22.69 185800 22.37 220200 22.04
145 - - - - - - - - - - - - - - - - - -
VZH170BG
1500 rpm
70 - - - - 42500 3.24 52300 3.09 63900 2.94 77500 2.76 93500 2.56 - - - -
90 - - - - 36400 4.49 45600 4.34 56400 4.20 69100 4.06 84000 3.89 101100 3.71 118700 3.50
110 - - - - - - 38500 5.79 48400 5.66 59900 5.54 73400 5.42 89000 5.29 105100 5.15
130 - - - - - - - - - - 49600 7.42 61500
7.34 75400 7.27 89800 7.20
140 - - - - - - - - - - - - 55000 8.52 67900 8.48 81400 8.43
145 - - - - - - - - - - - - - - - - - -
3600 rpm
70 72200 8.57 77500 8.51 97800 8.34 122500 8.16 152100 7.93 187300 7.64 228600 7.27 - - - -
90 62900 10.89 67900 10.85 86800 10.71 109500 10.58 136600 10.43 168700 10.24 206300 9.99 250100 9.65 295200 9.26
110 - - - - - - 95500 13.53 119500 13.42 147900 13.30 181400 13.14 220400 12.91 260800 12.64
130 - - - - - - - - - - 124400 17.17 153100 17.06 186800 16.92 222000 16.73
140 - - - - - - - - - - - - 137500 19.42 168400 19.31 200800 19.16
145 - - - - - - - - - - - - 129400 20.72 158800 20.62 189700 20.48
6000 rpm
70 - - - - 163000 15.07 203700 15.14 252300 14.98 309700 14.52 377000 13.70 - - - -
90 - - - - 145400 18.58 183400 18.84 228600 18.96 281900 18.88 344200 18.52 416500 17.83 490900 16.85
110 - - - - - - 160500 23.37 201200 23.61 249100 23.74 305300 23.70 370600 23.41 438100 22.87
130 - - - - - - - - - - 210500 29.72 259500 29.82 316800 29.77 376300 29.54
140 - - - - - - - - - - - - 233700 33.44 286600 33.45 341800 33.31
145 - - - - - - - - - - - - - - - - - -
To: Evaporating temperature in °F Superheat = 10 K Presented data are for models with motor voltage code G
Tc: Condensing temperature in °F Subcooling = 0 K
Qo: Cooling capacity in Btu Pe: Power input in kW
