Single compressorsTechnical specications
Capacity at ARI rating conditions - Low pressure ratio - VZH088BG - VZH117BG - VZH170BG
Models
rpm
Freq (Hz)
To -13 -10 0 10 20 30 40 50 59
Tc Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe
VZH088BG
1500 rpm
25
70 - - 21800 1.85 26400 1.76 31800 1.67 37900 1.60 45000 1.54 53000 1.51 - - - -
90 - - 18300 2.46 22700 2.39 27700 2.31 33400 2.24 39900 2.16 47400 2.09 55900 2.04 65400 2.00
110 - - - - 19000 3.12 23600 3.09 28800 3.03 34900 2.97 41700 2.90 49600 2.82 58400 2.75
130 - - - - - - - - 24100 4.08 29600 4.05 35800 4.01 43000 3.94 51200 3.87
140 - - - - - - - - - - 26800 4.73 32900 4.70 39700 4.65 47600 4.59
145 - - - - - - - - - - - - - - - - - -
3600 rpm
60
70 39900 4.56 49200 4.54 60200 4.46 73300 4.35 88600 4.25 106300 4.18 126400 4.17 - - - -
90 34900 5.73 43700 5.80 54200 5.78 66300 5.70 80500 5.57 96700 5.44 115200 5.34 136200 5.28 159700 5.31
110 - - - - 48000 7.36 59200 7.35 72000 7.26 86700 7.13 103400 6.99 122400 6.85 143700 6.76
130 - - - - - - - - 62300 9.36 75400 9.29 90200 9.16 107100 9.01 126100 8.86
140 - - - - - - - - - - 69100 10.56 83000 10.46 98800 10.32 116700 10.17
145 - - - - - - - - - - - - 79300 11.17 94700 11.04 112100 10.88
6000 rpm
100
70 - - 80700 7.83 98000 7.83 118400 7.78 142400 7.75 170300 7.81 202300 8.01 - - - -
90 - - 73500 10.14 90200 10.24 109700 10.20 132500 10.10 158800 10.00 188900 9.96 223100 10.05 261700 10.34
110 - - - 80400 12.79 98300 12.89 119000 12.83 142900 12.69 170300 12.52 201500 12.39 236800 12.38
130 - - - - - - - - 102000 15.83 122800 15.76 146800 15.58 174200 15.35 205500 15.15
140 - - - - - - - - - - 111400 17.40 133400 17.26 158800 17.03 187900 16.78
145 - - - - - - - - - - - - - - - - - -
VZH117BG
1500 rpm
25
70 - - 29200 2.44 35500 2.31 42600 2.20 50900 2.10 60300 2.03 71100 1.98 - - - -
90 - - 24600 3.23 30400 3.14 37100 3.04 44800 2.94 53600 2.84 63600 2.75 75000 2.68 87800 2.62
110 - - - - 25500 4.10 31600 4.05 38700 3.98 46800 3.90 56000 3.81 66500 3.71 78400 3.61
130 - - - - - - - - 32300 5.36 39700 5.32 48100 5.26 57700 5.18 68700 5.08
140 - - - - - - - - - - 36000 6.21 44100 6.18 53300 6.11 63800 6.02
145 - - - - - - - - - - - - - - - - - -
3600 rpm
60
70 53600 5.99 66000 5.96 80900 5.86 98400 5.72 119000 5.58 142600 5.49 169700 5.47 - - - -
90 46800 7.52 58700 7.62 72700 7.60 89100 7.48 108000 7.32 129800 7.15 154600 7.01 182800 6.94 214400 6.97
110 - - - - 64500 9.66 79400 9.65 96700 9.54 116400 9.37 138800 9.18 164300 9.00 192800 8.88
130 - - - - - - - - 83600 12.29 101200 12.20 121100 12.03 143700 11.83 169200 11.64
140 - - - - - - - - - - 92700 13.86 111400 13.74 132700 13.56 156700 13.35
145 - - - - - - - - - - - - 106500 14.66 127100 14.50 150400 14.30
6000 rpm
100
70 - - 108400 10.28 131500 10.28 159000 10.22 191200 10.18 228600 10.25 271500 10.52 - - - -
90 - - 98600 13.31 121000 13.45 147300 13.40 177900 13.27 213100 13.13 253500 13.08 299400 13.20 351300 13.58
110 - - - - 108000 16.80 131900 16.93 159800 16.85 191800 16.66 228600 16.44 270500 16.28 317900 16.26
130 - - - - - - - - 137000 20.79 164800 20.69 197000 20.46 233800 20.17 275800 19.90
140 - - - - - - - - - - 149500 22.85 179100 22.66 213200 22.37 252300 22.04
145 - - - - - - - - - - - - - - - - - -
VZH170BG
1500 rpm
25
70 - - 41700 3.30 50400 3.16 60500 3.03 72300 2.89 85800 2.73 101400 2.54 - - - -
90 - - 35800 4.56 44100 4.42 53700 4.29 64800 4.16 77500 4.02 92100 3.88 108700 3.71 127500 3.50
110 - - - - 37600 5.86 46400 5.74 56600 5.62 68400 5.52 81900 5.41 97300 5.29 114800 5.15
130 - - - - - - - - 47700
7.49 58300 7.41 70600 7.34 84600 7.27 100600 7.20
140 - - - - - - - - - - 53000 8.57 64600 8.52 77900 8.48 93200 8.43
145 - - - - - - - - - - - - - - - - - -
3600 rpm
60
70 77200 8.57 95400 8.41 117000 8.25 142700 8.07 172800 7.85 207800 7.57 248200 7.23 - - - -
90 68100 10.89 85300 10.77 105500 10.65 129300 10.52 157100 10.38 189300 10.20 226500 9.96 269000 9.65 317300 9.26
110 - - - - 93300 13.58 114800 13.49 139800 13.39 168800 13.27 202300 13.12 240800 12.91 284700 12.64
130 - - - - - - - - 120600 17.23 146000 17.15 175500 17.05 209600 16.92 248700 16.73
140 - - - - - - - - - - 134000 19.50 161400 19.41 193300 19.31 230000 19.16
145 - - - - - - - - - - - - 154500 20.71 185300 20.62 220900 20.48
6000 rpm
100
70 - - 159000 15.00 194900 15.13 237100 15.11 286400 14.88 343600 14.39 409300 13.59 - - - -
90 - - 142700 18.46 176700 18.72 216500 18.90 262800 18.96 316300 18.83 377800 18.47 448000 17.83 527600 16.85
110 - - - - 156700 23.23 193100 23.47 235400 23.66 284300 23.75 340600 23.68 405000 23.41 478200 22.87
130 - - - - - - - - 203700 29.60 247200 29.75 297400 29.83 355300 29.77 421500 29.54
140 - - - - - - - - - - 227200 33.36 274300 33.45 328800 33.45 391500 33.31
145 - - - - - - - - - - - - - - - - - -
To: Evaporating temperature in °F Superheat = 11.1 K Presented data are for models with motor voltage code G
Tc: Condensing temperature in °F Subcooling = 8.3 K
Qo: Cooling capacity in Btu Pe: Power input in kW
