Danfoss VZH Series Application Guidelines

Application guidelines
20 FRCC.PC.023.A7.22
Single compressorsTechnical specications
Capacity at EN12900 rating conditions - Low pressure ratio - VZH088BH - VZH117BH - VZH170BH
Models
rpm
Freq (Hz)
To -13 -10 0 10 20 30 40 50 59
Tc Qo Qo Qo Qo Qo Qo Qo Qo Qo
VZH088BG
1500 rpm
25
70 - - 22200 27400 33500 40600 48900 - -
90 - - 18700 23500 29100 35600 43200 51900 60900
110 - - - 19500 24600 30500 37400 45400 53500
130 - - - - - 25100 31300 38400 45700
140 - - - - - - 28000 34600 41500
145 - - - - - - - - -
3600 rpm
60
70 37300 40000 50400 63000 78100 95800 116500 - -
90 32200 34800 44500 56200 70000 86200 105000 126600 148600
110 - - - 49200 61600 76000 92800 112000 131600
130 - - - - - 64300 78800 95500 112500
140 - - - - - - 70800 86100 101900
145 - - - - - - 66500 81100 96200
6000 rpm
100
70 - - 82400 102000 125600 153600 186400 - -
90 - - 74500 93200 115500 141600 172100 207400 243500
110 - - - 82000 101900 125400 152700 184400 216900
130 - - - - - 104800 128100 155300 183400
140 - - - - - - 113800 138400 164000
145 - - - - - - - - -
VZH117BG
1500 rpm
25
70 - - 29800 36800 45000 54500 65600 - -
90 - - 25100 31500 39100 47800 58000 69700 81700
110 - - - 26200 33000 41000 50200 60900 71800
130 - - - - - 33700 41900 51500 61300
140 - - - - - - 37500 46500 55700
145 - - - - - - - - -
3600 rpm
60
70 50100 53700 67600 84500 104800 128600 156400 - -
90 43300 46700 59800 75400 94000 115700 140900 169900 199500
110 - - - 66000 82700 102100 124500 150300 176700
130 - - - - - 86300 105700 128100 151100
140 - - - - - - 95000 115600 136700
145 - - - - - - 89200 108900 129100
6000 rpm
100
70 - - 110500 136900 168600 206200 250200 - -
90 - - 100000 125100 155000 190100 231000 278400 326800
110 - - - 110000 136800 168300 205000 247500 291200
130 - - - - - 140600 172000 208500 246200
140 - - - - - - 152700 185800 220200
145 - - - - - - - - -
VZH170BG
1500 rpm
25
70 - - 42500 52300 63900 77500 93500 - -
90 - - 36400 45600 56400 69100 84000 101100 118700
110 - - - 38500 48400 59900 73400 89000 105100
130 - - - - - 49600 61500 75400 89800
140 - - - - - - 55000 67900 81400
145 - - - - - - - - -
3600 rpm
60
70 72200 77500 97800 122500 152100 187300 228600 - -
90 62900 67900 86800 109500 136600 168700 206300 250100 295200
110 - - - 95500 119500 147900 181400 220400 260800
130 - - - - - 124400 153100 186800 222000
140 - - - - - - 137500 168400 200800
145 - - - - - - 129400 158800 189700
6000 rpm
100
70 - - 163000 203700 252300 309700 377000 - -
90 - - 145400 183400 228600 281900 344200 416500 490900
110 - - - 160500 201200 249100 305300 370600 438100
130 - - - - - 210500 259500 316800 376300
140 - - - - - - 233700 286600 341800
145 - - - - - - - - -
To: Evaporating temperature in °F Superheat = 10 K Presented data are for models with motor voltage code G
Tc: Condensing temperature in °F Subcooling = 0 K
Qo: Cooling capacity in Btu Pe: Power input in kW
