Dantherm CDP 85 - Technical Information; Technical Data

Technical information: Technical data
en
Technical information
Specication Unit CDP 85 CDP 135 CDP 175
Operational humidity range % RH 40-100 40-100 40-100
Operational temperature
range
°C 15-38 15-38 15-38
Air volume, nominal m³/h 1500 2500 3600
Air volume, range m³/h 500-1500 1200-2500 1500-3600
Dehumidication capacity***
@ 20°C/60% l/24h 56 75 N/A
@ 30°C/60% l/24h 88 165 N/A
Max. external pressure loss *** Pa 300 350 N/A
Power supply V/Hz 1 × 230/50 1 × 230/50 -
- 3 x 400/50 3 x 400/50
Max. power consumption kW 2,0 3,6*/N/A** 6,0
Max. current A 9,5 16,3* / N/A** 9,1
Locked Rotor Amps (LRA) A 21 70*/25** 38
R454C gas weight/CO₂ equiv-
alent
kg/t 1,2 / 0,18 1,5 / 0,22 1,7 / 0,25
GWP (Global Warming
Potential)
- 148
Sound level @ 1 meter (nom-
inal)
dB(A) 58 60 63
Weight kg 130 160 190
Dimensions (w x d x h) mm 1155x725x650 1300x900x850 1400x1010x975
*1x230V, **3x400V, ***Nominal air volume
Technical data
29
