AUTOMATIC DIAGNOSTIC SELF-TEST - ON START UP
Press the power ON button to energize the panel. The following messages will be displayed as the panel proceeds through the
Automatic Diagnostic Self-Test. The Automatic Diagnostic Self-Test takes approximately 30 seconds.
Display Message 1
DATA ALARM PROCESSOR III
MODEL xxx-xxx-xxx BOOTLOADER REV x.xx
Display Message 2
DATA ALARM PROCESSOR III
MODEL nnn-nnn-nnn SOFTWARE REV; n.nn
Display Message 3*
DATA ALARM PROCESSOR III
MODEL nnn-nnn-nnn CONTROL MODULE
Display Message 4*
DATA ALARM PROCESSOR III
MODEL nnn-nnn-nnn EXPANSION MODULE
Display Message 5*
DATA ALARM PROCESSOR III
MODEL nnn-nnn-nnn RELAY MODULE
Display Message 6*
DATA ALARM PROCESSOR III
MODEL nnn-nnn-nnn ANALOG MODULE
Display Message 7*
DATA ALARM PROCESSOR III
MODEL nnn-nnn-nnn (Comm Card) MODULE
Display Message 8
DATA ALARM PROCESSOR III SELF-TEST
FLASH: PASS
Display Message 9
DATA ALARM PROCESSOR III SELF-TEST
STATIC RAM: PASS
Display Message 10
DATA ALARM PROCESSOR III SELF-TEST
PARAMETERS: PASS
Display Message 11
DATA ALARM PROCESSOR III SELF TEST
RAM SIGNATURE: PASS
Display Message 12
DATA ALARM PROCESSOR III SELF-TEST
ANALOG: PASS
Display Message 13
DATA ALARM PROCESSOR III SELF-TEST
12 VDC REGULATED: nn.n PASS
Display Message 14
DATA ALARM PROCESSOR III SELF-TEST
5VDC REGULATED: nn.n PASS
Display Message 15
DATA ALARM PROCESSOR III SELF-TEST
BATTERY VOLTAGE: n.n PASS
Display Message 16
DATA ALARM PROCESSOR III SELF-TEST
RETURN TEMP SENSOR: PASS
Display Message 17
DATA ALARM PROCESSOR III SELF-TEST
DISCHARGE TEMP SENSOR: PASS
Display Message 18
DATA ALARM PROCESSOR III SELF-TEST
HUMIDITY SENSOR: PASS
Display Message 19
DATA ALARM PROCESSOR III SELF-TEST
BUTTONS: PASS
* Only displays when these modules or
communication cards are connected.
If there is a failure during the
Automatic Self-Test, the display will
stop scrolling and only the message
with the failure will be displayed.
To allow the processor to continue
the self-test after a failure has been
displayed, press the MENU  button.
See Menu 3-6 Automatic Self-Test
Acknowledge toggle. When the
self-test is complete, the timed Start
Delay will be displayed.
Display Message
DATA ALARM PROCESSOR III
START DELAY: mm:ss
After the timed start delay is
complete, the unit will start and
the processor will be in operating
mode. The following pages are
typical displays for each menu, with
available selections, options and/
or values. Factory settings are also
listed.
