51
Group 7
MENU -To view group 7
Display will read: GROUP 7 – CALIBRATION
SELECT - To view sub menu 7-1:
Display will read: GROUP 7 -1 CALIBRATE TEMPERATURE SENSOR
SELECT or - To view current setting
Display will read: 7-1 CALIBRATE TEMPERATURE SENSOR
RETURN TEMP: nn.n + n.n = nn.n F (C)
The temperature sensor is CALIBRATED and the offset is entered at the factory. Each sensor is tagged with
the calibration offset. This should be verifi ed with the setting that appears on the display.
SELECT or - To change the offset. Offset ranges from -20.0 to 20.0 in .01 degree increments.
MENU - To advance to next sub-menu
Display will read: 7 - 2 CALIBRATE HUMIDITY SENSOR
SELECT or - To view current setting
Display will read: 7-2 CALIBRATE HUMIDITY SENSOR
HUMIDITY: nn.n + nn.n = nn.n %
The humidity sensor is CALIBRATED and the offset is entered at the factory. Each sensor is tagged with the
calibration offset. This should be verifi ed with the setting that appears on the display.
SELECT or - To change the offset. Humidity will only range between 20 to 80%. The range of
offset is dependent on the current humidity.
MENU - To advance to next sub-menu
Display will read: 7 - 3 CALIBRATE DISC. AIR TEMP SENSOR
SELECT or - To view current setting
Display will read: 7-3 CALIBRATE DISC. AIR TEMP SENSOR
DISCHARGE TEMPERATURE: nn.n - nn.n = nn.n F (C)
The discharge air temperature sensor is CALIBRATED and the offset is entered at the factory. Each sensor
is tagged with the calibration offset. This should be verifi ed with the setting that appears on the display.
SELECT or - To change the offset. Temperature offset ranges +/- 9.9
0
in 0.1
0
increments.
NOTE: Discharge air temperature sensor is optional. If the unit was ordered without the option
the display will read SENSOR NOT INSTALLED when looking for current setting.
