Data Aire DAP III User Manual

87
Hard Power ON/OFF
Blower
Cool 1
Cool 2
Reheat
Humidifi er
Manual Override Switches
On all DAP III control modules there are six manual over ride switches. These switches are on
the board and to access the cover has to be opened. As discussed in the beginning of this man-
ual the fi rst or top switch is the “hard” power ON/OFF switch. The next switches in order are for
the blower, cool 1, cool 2, reheat, and humidifi er. In testing the unit or in the event of a failure
of the electronic circuitry these switches can be turned to the ON position to operate the com-
ponents. Regardless of the programming in the DAP III each component that is turned on will
remain operational until the respective manual over ride switch is returned to the OFF position.
