46
MENU - To Group 6 - NETWORK
SELECT - To view Group 6 sub-menus
Display will read: 6-1 UNIT & NETWORK ID
SELECT or - To view current setting
Display will read: 6-1 UNIT & NETWORK ID
UNIT & NETWORK ID: nnn
SELECT or - To change current setting
Units may given a numerical ID from 001 to 260. Units cannot share the same ID. Units
will not respond to a network unless a separate ID is entered for each unit.
Factory setting is: UNIT & NETWORK ID: 001
MENU - To view next sub-menu
Display will read: 6-2 NETWORK PROTOCOL
SELECT or - To view current setting
Display will read: 6-2 NETWORK PROTOCOL
aaaaaaaaaaaaaaaaaaaa
Data Aire offers protocols to interface with a number of building management systems
(BMS). Units must be provided with optional communication cards.
The following choices are available:
BACNET IP BACNET MS/TP MASTER BACKNET MS/TP SALVE
LONWORKS JOHNSON CONTROLS MODBUS TCP
MODBUS RTU MODBUS ASCII METASYS N2 SNMPv1/v2c
Factory setting is based on protocol ordered. The appropriate protocol will be factory set.
MENU - To view next sub-menu
Display will read: 6-3 IP ADDRESS
SELECT or - To view current setting
Display will read: 6-3 IP ADDRESS
IP ADDRESS OCTET 1: 0. 0. 0. 0
SELECT or - To change current setting - This applies to all OCTET settings
MENU - To view OCTET 2
Display will read: 6-3 IP ADDRESS
IP ADDRESS OCTET 2: 0. 0. 0. 0
Group 6
Menus 6-2 to 6-15 are locked.
To modify you have to unlock
the DAP III.
If protocol is changed the DAP
III panel needs to be reset.
Turn panel OFF then ON.
To Next Page
