Data Aire DAP III User Manual

44
PRIMARY/SECONDARY PRIMARY/SECONDARY
FOUR TANDEM COMPRESSORS
NONE
MENU  - To view next sub-menu
Display will read: 5-5 REHEAT STAGES
SELECT  or  - To view current setting
Display will read: 5-5 REHEAT STAGES
REHEAT STAGES: 1 HOT WATER
SELECT  or  -
To view alternate setting
NONE
1
2
3 (OR VALUE ON P15-16, P15-17)
MENU  - To view next sub-menu
Display will read: 5-6 HUMIDIFIER
SELECT  or  - To view current setting
Display will read: 5-6 HUMIDIFIER
HUMIDIFIER: COMPUTER, NON-MODULATING
SELECT  or  - To view alternate setting
COMPUTER, MODULATING
COMFORT, NON-MODULATING
COMFORT, MODULATING
NONE
MENU  - To view next sub-menu
Display will read: 5-7 WATER VALVE MODE
SELECT  or  - To view current setting
Display will read: 5-7 WATER VALVE MODE
WATER VALVE: NONE
SELECT  or  - To view alternate setting
WATER VALVE: CHILLED WATER COOLING
WATER VALVE: ENERGY SAVER COOLING
WATER VALVE: AUX CHILLED WATER COOLING
WATER VALVE: CHILLED WATER DISC REG
Factory setting is: NONE
MENU  - To view next sub-menu
Factory setting for 5-5 is
dependent on the equipment and
options selected. If reheat has
been deleted the factory setting is
NONE. If the unit is a fl oor mount
or LCS unit without additional
reheat the factory setting is 3. If
the unit is a ceiling, non LCS, the
factory setting is 1.
Factory setting for 5-6 is also
dependent on the equipment and
options selected. If humidifi ca-
tion has been deleted the factory
setting is NONE. If the unit does
not have optional humidifi cation
the setting is: COMPUTER, NON-
MODULATING. If the unit has
optional humidifi cation the setting
is: COMPUTER, MODULATING.
