Data Aire DAP III User Manual

62
MENU  - To view next sub-menu
Display will read: 10-2 SPECIFY SENSOR 1 UNITS OF MEASURE
SELECT  - To view current setting
Display will read: 10-2 SPECIFY SENSOR 1 UNITS OF MEASURE
VAC (AC VOLTS)
SELECT  or  - To change setting.
AMPS (AMPERES)
HZ (HERTZ)
KW (KILOWATTS)
F (DEGREES FAHRENHEIT)
C (DEGREES CENTIGRADE)
GPM (GALLONS PER MINUTE)
%RH (PERCENT RELATIVE HUMIDITY)
PSIG (POUNDS PER SQUARE INCH)
“H2O (INCHES OF WATER)
PSI (POUNDS PER SQUARE INCH)
% (PERCENT)
MENU  - To view next sub-menu
Display will read: 10-3 SPECIFY SENSOR 1 SIGNAL RANGE
SELECT  - To view current setting
Display will read: 10-3 SPECIFY SENSOR 1 UNITS OF MEASURE
0-10 VDC
SELECT  or  - To change setting.
0-5 VDC
4-20 MA
MENU  - To view next sub-menu
Display will read: 10-4 SPECIFY SENSOR 1 MINIMUM VALUE
SELECT  - To view current setting
Display will read: 10-4 SPECIFY SENSOR 1 MINIMUM VALUE
0 VDC SIGNAL = 0.0 VAC
SELECT  or  - To change setting.
0 VDC SIGNAL = 100.0 VAC
0 VDC SIGNAL = 200.0 VAC
0 VDC SIGNAL = 300.0 VAC
0 VDC SIGNAL = 400.0 VAC
0 VDC SIGNAL = 500.0 VAC
0 VDC SIGNAL = 600.0 VAC
0 VDC SIGNAL = 700.0 VAC
0 VDC SIGNAL = 800.0 VAC
0 VDC SIGNAL = 900.0 VAC
NOTE - In addition to
programming sub-menu
10-3 you must set the
micro switches on the
Analog Module, as
described on page 78.
NOTE - Unit of measure
will change based on se-
lection in sub menu 10-2.
