MENU - To view next sub-menu
Display will read: 10-5 SPECIFY SENSOR 1 MAXIMUM VALUE
SELECT - To view current setting
Display will read: 10-5 SPECIFY SENSOR 1 MAXIMUM VALUE
10 VDC SIGNAL = 0.0 VAC
SELECT or - To change setting.
10 VDC SIGNAL = 100.0 VAC
10 VDC SIGNAL = 200.0 VAC
10 VDC SIGNAL = 300.0 VAC
10 VDC SIGNAL = 400.0 VAC
10 VDC SIGNAL = 500.0 VAC
10 VDC SIGNAL = 600.0 VAC
10 VDC SIGNAL = 700.0 VAC
10 VDC SIGNAL = 800.0 VAC
10 VDC SIGNAL = 900.0 VAC
MENU - To view next sub-menu
Display will read: 10-6 SET SENSOR 1 CALIBRATION
SELECT - To view current setting
Display will read: 10-6 SET SENSOR 1 CALIBRATION
0.0 + 0.0 = 0.0
SELECT or - To change the calibration. The fi rst value in the calibration formula is the minimum
value set in submenu 10-4, this value can range from 0 to 900. The next value in the above equation is the calibration
range, adjustment, which can be changed in 0.1 of degree increments either positive or negative.
The calibration range, adjustment, is dependent on the values set for the maximum and minimums. Adjustment
range will be the MAXIMUM VALUE, set in sub-menu10-5, less the MINIMUM VALUE, set in sub menu 10-4, divided
by 10. For example if you had set sub-menu 10-5, MAXIMUM VALUE, at 800 and sub-menu 10-4, MINIMUM VALUE,
at 200 then the calibration range would be 60 (800-200=600/10=60), in 0.1 increments.
NOTE: In no circumstances should the MINIMUM value be greater than the MAXIMUM
value.
There are four sensor input with the same menu options as 10-1 through 10-6 except they are for
the other three sensors. See submenu reference below.
Sensor 1 Sensor 2 Sensor 3 Sensor 4
Sensor Name Submenu 10-1 Submenu 10-7 Submenu 10-13 Submenu 10-19
Unit of Measure Submenu 10-2 Submenu 10-8 Submenu 10-14 Submenu 10-20
Signal Range Submenu 10-3 Submenu 10-9 Submenu 10-15 Submenu 10-21
Minimum Value Submenu 10-4 Submenu 10-10 Submenu 10-16 Submenu 10-22
Maximum Value Submenu 10-5 Submenu 10-11 Submenu 10-17 Submenu 10-23
Calibration Submenu 10-6 Submenu 10-12 Submenu 10-18 Submenu 10-24
