PIN IDENTIFICATION FOR DAP III MODULES
PIN Identifi cation DAP III Connector PIN No. DAP III Cable No.
STANDARD CONTROL MODULE
24VAC ISOLATION TR. P5-1 1
24VAC COMMON ISOLATION TR. P5-2 2
24 VAC P5-3 2A
24 VAC COMMON. P5-4 3A
BLOWER P6-1 4
COMPRESSOR 1 P6-2 5
COMPRESSOR 2 P6-3 6
REHEAT 1 P6-4 7
HUMIDIFIER P6-5 8
STATUS CONTACT COMMON P6-6 9
STATUS CONTACT N.O P6-7 10
ALARM 1 CONTACT COMMON P6-8 11
ALARM 1 CONTACT N.C P6-9 12
ALARM 1 CONTACT N.O P6-10 13
OPTIONAL ALARM INPUT 1 P7-1 14
OPTIONAL ALARM INPUT 2 P7-2 15
OPTIONAL ALARM INPUT 3 P7-3 16
HIGH CONDENSATE WATER LEVEL P7-4 17
NO AIR FLOW P7-5 18
+5VDC TO HUMIDITY SENSOR P8-1
HUMIDITY SENSOR + P8-2 SENSORS ARE
HUMIDITY SENSOR - P8-3 DIRECTLY CONNECTED
RETURN AIR TEMP SENSOR+ P8-4 TO THE BOARD
RETURN AIR TEMP SENSOR- P8-5 USING SHIELDED CABLE.
STANDARD CONTROL EXPANSION MODULE
24 VAC P9-1 2B
24 VAC COMMON. P9-2 3B
ENERGY SAVER AVAILABLE OUTPUT P10-1 19
REHEAT 2 P10-2 20
REHEAT 3 P10-3 21
OPTIONAL ALARM INPUT 4 P11-1 22
DIRTY FILTER P11-2 23
HUMIDIFIER FAILURE P11-3 24
HP FAILURE COMPRESSOR 1 P11-4 25
LP FAILURE COMPRESSOR 1 P11-5 26
HP FAILURE COMPRESSOR 2 P11-6 27
LP FAILURE COMPRESSOR 2 P11-7 28
SMOKE DETECTOR P11-8 29
NO WATER FLOW ALARM P11-9 30
ENERGY SAVER INPUT P11-10 31
DISCHARGE TEMP SENSOR + P12-1 SENSORS ARE
DISCHARGE TEMP SENSOR - P12-2 DIRECTLY CONNECTED
CHILLED WATER TEMP SENSOR + P12-3 TO THE BOARD
CHILLED WATER TEMP SENSOR - P12-4 USING SHIELDED CABLE.
FLOOR WATER SENSOR P12-5 32
FLOOR WATER SENSOR P12-6 33
+ 0-10VDC TO WATER VALVE P13-1 34
- 0-10VDC TO WATER VALVE P13-2 35
OPTIONAL RELAY MODULE
24VAC IN P15-1 36
COOLING 3RD STAGE P15-2 37
COOLING 4TH STAGE P15-3 38
AUTOFLUSH TIMER P15-4 39
ALARM 2 CONTACT COMMON P15-5 40
ALARM 2 CONTACT N.C P15-6 41
ALARM 2 CONTACT N.O P15-7 42
ALARM 3 CONTACT COMMON P15-8 43
ALARM 3 CONTACT N.C P15-9 44
ALARM 3 CONTACT N.O P15-10 45
CONDENSER AUX. CONTACT P15-11 46
CONDENSER AUX. CONTACT P15-12 47
ALARM 4 CONTACT COMMON P15-13 48
ALARM 4 CONTACT N.C P15-14 49
ALARM 4 CONTACT N.O P15-15 50
MODULATING HUMIDIFIER VDC+ P15-16 51
MODULATING HUMIDIFIER VDC- P15-17 52
