DataCard SD260L Installation And Administrator's Guide

SD260L/SD360/SD460 Installation and Administrator’s Guide 99
Optional Equipment
The following optional equipment is available.
Large Output Hopper
The printer can use a large output hopper, which holds about
100 cards. You can replace the small, standard hopper with the
large hopper without using tools.
200-Card Input Hopper
The 200-card input hopper kit includes the larger hopper with an attached cover. The standard
hopper is easily removed and the 200-card hopper can be installed without using tools.
Cable Lock
The printer can be used with a cable lock. Obtain the lock from your dealer, because it includes an
added security plate that is inserted into the printer.

DataCard SD260L Specifications

General

Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC
Card feeder	Yes
Duplex printing	No
Print technology	Dye-sublimation/Resin Thermal transfer
Maximum resolution	300 x 300 DPI
Print speed (color)	830 card/h
Print speed (monochrome)	200 card/h
Display	LCD
Product color	Blue, Grey
Internal memory	128 MB
Cable lock slot type	Kensington
Total input capacity	100 sheets
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
USB version	2.0
Ethernet interface type	Fast Ethernet
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64

Weight and Dimensions

Depth	539 mm
Width	175 mm
Height	224 mm
Weight	5400 g
