DataCard SD460 Installation And Administration Guide

6 Installation
Load the Print Ribbon
Loadtheribbonwhenyouinstalltheprinterandwhentheribbonrunsout.
1. Opentheprintercover.
2. Removetheprintribboncartridge.
3. Loadafullrollofprintribbon(theblue
spool)ontothespindleclosesttothe
cartridgehandle.
4. Placethesilvertake‐upspoolonthe
spindlewiththeblackgear.
5. Windthetake‐upspool
counterclockwiseonefullturn.
Load the Cleaning Sleeve
Loadanewcleaningsleevewitheachnewroll
ofprintribbon,ifyounoticedebrisonthe
printedcards,orifthecleaningsleeveisno
longersticky.
Theprintershipswiththecleaningroller
spindleinstalledontheprintribbon
cartridge.
1. Removethecleaningrollerspindlefrom
theribboncartridgeandslidethespindle
intothecontinuouscleaningsleeve(a).
2. Placethespindlewithcleaningsleeve
ontotheribboncartridge(b).
3. Removetheprotectivewrapperfromthecleaningsleeve(c).

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
