DataCard SD460 Installation And Administration Guide

A-6 SD460 Laminating System
Assemble the Printer and Laminator
1. Locatetheinterconnectcableinthe
cableroutingareaofthelaminator
andmakesurethatitremains
accessible.
2. Openthelaminatoraccessdoor.
3. Slidetheprinterlockingleverinthe
laminatortothelefttopositionthe
mountinglockintheunlocked
state.
4. Lifttheprinteroverthelaminator
andalignthepinsonthelaminatorwiththe
holesontheundersideoftheprinter.
5. Pressdownontheprintercarefully,butfirmly,
topositionit.
6. Pushtheprinterlockinglevertotherightto
locktheprinterontothelaminator.Makesure
thattheprinterissecurelylockedtothe
laminator.
7. Closethelaminatoraccessdoor.
Interconnect
Cable
Lock
Unlock
Printer Locking
Lever

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
