DataCard SD460 User Manual

B-2 Windows Server 2008 and 2012 Printer Sharing
3. Write down the printer name and host PC name.
a. Display the Devices and Printers window. Select the card printer icon and click Print
server properties in the menu bar. The Printer Properties window displays.
b. Select the General tab on the Printer Properties window to display the printer device
name.
c. Write down the name of the printer.
d. Display the System properties window for your computer.
e. Write down the host PC name found in the Full Computer Name field.
f. Close the System properties window.
4. Enable printer sharing.
a. Select the Sharing tab on the Printer Properties window.
b. Click Change Sharing Options. The shaded fields become active.
c. Select Share this printer.
Make sure that a printer name displays in the Share name field. Refer to “Printer Sharing
Requirements” on page 28 for more information about naming the host printer.
d. Select Render print jobs on client computers.
e. Click Apply to apply these settings.
Remember to record the printer device name. You need this printer name to
install the Card Printer Driver on the client PC.
The printer Share name is assigned by the Windows operating system. This
displays as the same printer name (or an abbreviated version of the printer
name) you wrote down earlier.

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
