D-200 MK2 User Manual Firmware V-6.3

L058D01-EN - 11 -

Dimensions: 133x107x46mm (5.25”x4.2”x1.9”)

Panel Cutout: 117x87mm minimum (4.6”x3.43”)

Weight: 250g (0.55 lb)

2.1. DIMENSIONS

2. MOUNTING
