The parameters below define the functions of relay outputs. The unit has 3 relay outputs. All relays have
programmable functions, selected from a list.
Parameter Definition
Factory
set
Terminal
number
Description
Relay-01
3
4
Factory set as Crank Relay output
Relay-02
1
5
Factory set as Fuel Relay output
Relay-03
2
6
Factory set as Horn Relay output
Below is a short list for reference purposes. Please use
the RainbowPlus program for complete selection list.
16.9. OUTPUT CONFIGURATION
