D-700 MK3 User Manual Firmware V-16.8

- 15 -

Two different types of brackets are provided:

Screw type bracket

Self retaining type bracket

Installation of screw type bracket

Installation of self-retaining type bracket

Do not tighten too much, this may break the unit.
