Datakom D-700 MK3 - Digital Outputs

D-700 MK3 User Manual Firmware V-16.8
- 25 -
The unit offers 8 digital outputs with programmable function, selectable from list.
Structure:
Negative pulling protected semiconductor output. One terminal is
connected to battery negative.
Max continuous current:
1.0 ADC
Max switching voltage:
33 VDC
Overvoltage protection:
40 VDC
Short circuit protection:
> 1.7 ADC
Reverse voltage
protection:
500 VDC
3.10. -
3.9. -
3.8. DIGITAL OUTPUTS
