Datakom DPR-400 User Manual

DPR-400 User Manual Rev_01 Firmware V-1.0
- 55 -
Parameter Definition
Unit
Min
Max
Factory
Setting
Description
Web Refresh Rate
Sec
0
240
5
The unit refreshes the Webpage
periodically at this interval.
Ping Period
Min
0
240
0
The unit checks the availability of
Internet connection at this interval.
Rainbow Refresh Rate
Sec
0
65535
60
The unit will update the remote
monitoring terminal at this rate.
Rainbow Scada
Address-1 Port
-
0
65535
90
This is the port number of the first
monitoring terminal address.
Rainbow Scada
Address-2 Port
-
0
65535
90
This is the port number of the second
remote monitoring terminal address.
Web Server Port
-
0
65535
80
This is the port number of the internal
Web server. The unit will respond to
queries to this port only.
Modbus TCP/IP Port
-
0
65535
502
This is the port number of the internal
Modbus TCP/IP terminal. The unit will
respond to Modbus requests to this port
only.
SMTP Port
-
0
65535
587
This is the port number used for e-mail
sending.
Ethernet Enable
-
0
1
1
0: Ethernet port OFF
1: Ethernet port ON
The adjustment screen for the unit’s real time clock is as shown below. Using the and buttons,
the parameter values can be changed. Pressing the button navigates to the next parameter. Pressing
and holding the button saves changes and returns to main menu. The button discards changes
and returns to main menu.
Date/Time Display
12.23. ETHERNET SETTINGS (continued)
The following Ethernet parameters are located under
Controller Configuration group.
Aşağıdaki Ethernet ile ilgili parametreler Cihaz
Konfigürasyonu grubu altında bulunurlar.
12.24. DATE & TIME SETTINGS
