REGISTER
ADDRESS
VARIABLE
DESCRIPTION
SIZE
R/W
TYPE
X
20480
V1 RMS
V1 Phase – Neutral
Voltage
32
R-O
Unsigned
long
x10
20482
V2 RMS
V2 Phase – Neutral
Voltage
32
R-O
Unsigned
long
x10
20484
V3 RMS
V3 Phase – Neutral
Voltage
32
R-O
Unsigned
long
x10
20486
I1 RMS
I1 Current
32
R-O
Unsigned
long
x1000
20488
I2 RMS
I2 Current
32
R-O
Unsigned
long
x1000
20490
I3 RMS
I3 Current
32
R-O
Unsigned
long
x1000
20492
IE RMS
Ground Current
32
R-O
Unsigned
long
x1000
20494
IEs RMS
Precise Ground
Current
32
R-O
Unsigned
long
x1000
20496
I1s RMS
Precise I1 Current
32
R-O
Unsigned
long
x1000
20498
I2s RMS
Precise I2 Current
32
R-O
Unsigned
long
x1000
20500
I3s RMS
Precise I3 Current
32
R-O
Unsigned
long
x1000
20502
V_2
Voltage Negative
Sequence
Component NSQ
32
R-O
Unsigned
long
x10
20504
I_2
Current Negative
Sequence
Component NSQ
32
R-O
Unsigned
long
x1000
20506
T32Q
T32Q
32
R-O
Unsigned
long
x100
20508
V_1
Voltage Positive
Sequence
Component PSQ
32
R-O
Unsigned
long
x10
20510
I_1
Current Positive
Sequence
Component PSQ
32
R-O
Unsigned
long
x1000
20512
V0
Voltage Zero
Sequence
Component ZSQ
32
R-O
Unsigned
long
x10
20514
I0
Current Zero
Sequence
Component ZSQ
32
R-O
Unsigned
long
x1000
20516
U12 RMS
U12 Phase – Phase
Voltage
32
R-O
Unsigned
long
x10
20518
U23 RMS
U23 Phase – Phase
32
R-O
Unsigned
x10
