Datakom DPR-400 - Transformer Configuration

DPR-400 User Manual Rev_01 Firmware V-1.0
- 42 -
Parameter Definition
Unit
Min
Max
Factory
Setting
Description
Voltage (VT) Primary
V
100
655350
100
Voltage transformer primary value.
Must be set to 100V if not used.
Voltage (VT) Secondary
V
10
600
100
Voltage transformer secondary value.
Must be set to 100 V if not used.
Current (CT) Primary
A
1
30000
500
Current transformer primary value
Current (CT) Secondary
-
0(5A)
1(1A)
0(5A)
0: 5A
1: 1A
This value is also used as nominal
current value (In).
Ground Current (CT)
Primary
A
1
30000
500
Current transformer primary value
Ground Current (CT)
Secondary
-
0(5A)
1(1A)
0(5A)
0: 5A
1: 1A
This value is also used as nominal
current value (In).
Nominal Frequency
Hz
50
69
50
Nominal frequency selection; 50 or
60Hz.
12.3. TRANSFORMER CONFIGURATION
