DPR-400 User Manual Rev_01 Firmware V-1.0
- 67 -
REGISTER
ADDRESS
VARIABLE
DESCRIPTION
SIZE
R/W
TYPE
X
20606
CnfgWord
Device Configuration
16
R-O
Unsigned
word
-
20607
IAPStatus
Flash write status
(0:ok 1:error)
16
R-O
Unsigned
word
x1
20608
ReadUnloc
Flash parameter read
unlock timer
16
R-O
Unsigned
word
x1
20609
PacketScc
Number of
successfully sent
packets
16
R-O
Unsigned
word
x1
20610
CB Status
Circuit Breaker
information
16
R-O
Unsigned
word
x1
20611
GprsIP
GPRS IP address
(Reserved)
4x8
R-O
Unsigned
char
x1
20613
TcpIP
Device IP address
4x8
R-O
Unsigned
char
x1
20615
DK_Mflg1
Ram output flags 1,
total 256 bits
20616
-
Reserved
2x16
R-O
Unsigned
word
x1
20618
Dig-out
Digital Output
Statuses
64
R-O
Long
Long
-
20622
MAC_adr
Ethernet MAC
address
6x8
R-O
Unsigned
char
x1
20625
WAN_IP
Ethernet WAN
address
4x8
R-O
Unsigned
char
x1
20627
ProtectFlgs
Protection flags
32
R-O
Unsigned
long
-
20629
Dig-int
Digital Input
Statuses
32
R-O
Unsigned
word
x1
20631
-
Reserved
16
R-O
Long
Long
-
20632
SaveResceParamFlags
Save Parameters
Rescue Registers
Flags
32
R-O
20634
IMEI
Modem IMEI number
(Reserved)
16x8
BIT
R-O
Unsigned
char
x1
BIT
DESCRIPTION
BIT
DESCRIPTION
0
Overcurrent Protection
9
Negative Sequence Voltage Protection
1
Negative Sequence Current Protection
10
Breaker Failure Protection
2
Broken Conductor Protection
11
Thermal Overload Protection
3
Neutral Current Protection
17
Current Transformer Monitoring Protection
7
High Voltage Protection
19
Under Frequency Protection
8
Under Voltage Protection
20
High Frequency Protection
14.11. FUNCTION ALARM INFORMATION
