Datakom DPR-400 - Matrix Input Information

DPR-400 User Manual Rev_01 Firmware V-1.0
- 69 -
BIT
DESCRIPTION
BIT
DESCRIPTION
0
Digital Input 1
33
IN > Start (IN: Neutral Overcurrent)
1
Digital Input 2
34
IN > Trip
2
Digital Input 3
35
IN >> Start
3
Digital Input 4
36
IN >> Trip
4
Digital Input 5
37
Cold Load Close
5
Digital Input 6
38
I2/I1 > Start (I1: Zero Component
Overcurrent)
6
Digital Input 7
39
I2/I1 > Trip
7
Digital Input 8
40
Idef > Start (Idef: Directional Neutral
Current)
8
Digital Input 9
41
Idef > Trip
9
Digital Input 10
42
Isef > Start ( Isef: Precise Neutral Current)
10
Digital Input 11
43
Isef > Trip
11
Digital Input 12
44
Isef >> Start
12
Digital Input 13
45
Isef >> Trip
13
Digital Input 14
46
VN > Start (VN: Residual Voltage)
14
Digital Input 15
47
VN > Trip
15
Digital Input 16
48
VN >> Start
16
Breaker Status
49
VN >> Trip
17
Watchdog Relay Status
50
T > Start (T: Thermal Overload)
18
I > Start (I: Overcurrent)
51
T > Trip
19
I > Trip
52
V < Start (V: Voltage)
20
I >> Start
53
V < Trip
21
I >> Trip
54
V << Start
22
I >>> Start
55
V << Trip
23
I >>> Trip
56
V > Start (V: Voltage)
24
I >>>> Start
57
V > Trip
25
I >>>> Trip
58
V >> Start
26
I2 > Start (I2: Negative Component
Overcurrent)
59
V >> Trip
27
I2 > Trip
60
VN > Start (VN: Negative Sequence
Voltage)
28
I2 >> Start
61
VN > Trip
29
I2 >> Trip
62
Successful Reclosure
30
Breaker Failure 1
63
f < Start (f: Frequency)
31
Breaker Failure 2
64
f < Trip
32
Automatic Reclosure
65
-
127
Reserved
14.13. MATRIX INPUT INFORMATION
