Focus Lock/Unlock
Once entered, the scanner automatically performs the Focus Lock procedure to save the
mechanical focus position to memory. If the mechanical focus position is changed by more
than the allowed tolerance of the value in memory, a diagnostic alarm will be sent to the
display.
The procedure is as follows:
- enter the Focus Lock function
- wait until the "Focus locked at..." message appears on the display (indicating the focus
position has been saved to memory). The following parameters are set:
• Locked Position = your mechanical setting
• Focus Displacement (Alarm) = set (default to display only)
If the Focus lock has already been set, this procedure can be used to Unlock the focus value.
In this case control of the focus position is disabled.
The scanner will restart at the end of the process.
Reset Scanner to Factory Default
If it ever becomes necessary to reset the scanner to the factory default values, you can
perform this procedure by holding the X-PRESS™ push button pressed while powering up
the scanner. At the end of the procedure (about 5-6 seconds), the Configuration and
Environmental parameters are reset, all LEDs blink simultaneously 3 times and the message
"Default Set" is shown on the display.
2.4 ACCESSORIES
The following accessories are available on request for the DS4800:
Name Description Part Number
BK-4000 L-Shape Bracket 93ACC1837
BK-4001 U-Shape Bracket 93ACC1838
CBX100 Compact Connection Box 93A301067
CBX100LT Compact Connection Box Low Temp 93A301069
CBX500 Modular Connection Box 93A301068
BM100 Backup Module 93ACC1808
BM150 Display Module 93ACC1809
BM300/310 Profibus Module STD/IP65 93ACC1810, 93ACC1811
BM400 DeviceNet Module IP65 93ACC1814
BM500/510/520 Ethernet Module STD/IP65/IP54 93ACC1812, 93ACC1813,
93ACC1840
BA100 DIN Rail Adapters 93ACC1821
BA200 Bosch Adapters 93ACC1822
PH-1 Photocell Kit PNP 93ACC1791
MEP-543 Photocell Kit NPN 93ACC1728
PG-6000/6001/6002 24 V Power Supply Unit EU/UK/US 93ACC1720, 93ACC1719,
93ACC1718
