DS4800 REFERENCE MANUAL
4
4.7
USER INTERFACE - HOST
The following table contains the pinout for standard RS232 PC Host interface. For other user
interface types please refer to their own manual.
RS232 PC-side connections
1
5
9
6
9-pin male connector
13
25
14
1
25-pin male connect
or
Pin Name Pin
Name
2 RX 3
RX
3 TX 2
TX
5 GND 7
GND
7 RTS 4
RTS
8 CTS 5
CTS
50
57
59
