Minimum Code Height for ACR4 Reading (mm)
45° max 30° max
Conveyor Speed (m/s) 0.5 1 1.5 2 2.5 3 0.5 1 1.5 2 2.5 3
0.25
10 12 15 18 21 24 7 9 11 14 16 18
0.30
11 13 16 19 22 25 7 10 12 14 16 19
0.33
11 14 17 20 22 26 8 10 12 14 17 19
0.38
12 15 18 21 23 26 8 11 13 15 17 20
0.50
15 17 20 23 26 29 10 12 14 16 19 21
0.72
19 22 25 27 30 33 12 15 17 19 21 24
Codabar
Code Resolution
(mm)
1.00
25 27 30 33 36 39 16 18 20 22 25 27
Ratio 3:1; Interdigit = Module Size
Table 4
Minimum Code Height for ACR4 Reading (mm)
45° max 30° max
Conveyor Speed (m/s) 0.5 1 1.5 2 2.5 3 0.5 1 1.5 2 2.5 3
0.25
9 12 15 18 21 23 7 9 11 13 16 18
0.30
10 13 16 19 22 24 7 9 12 14 16 18
0.33
11 14 16 19 22 25 8 10 12 14 17 19
0.38
12 15 17 20 23 26 8 10 13 15 17 19
0.50
14 17 20 22 25 28 9 12 14 16 18 21
0.72
18 21 24 27 29 32 12 14 16 19 21 23
EAN 8-13, UPC-A
Code Resolution
(mm)
1.00
24 26 29 32 35 38 15 17 19 22 24 26
Table 5
