Selecting the Interface Type
16 Gryphon™ I GBT4100
Selecting the Interface Type
Upon completing the physical connection between the
reader and its host, proceed directly to Interface Selection
on page 16 for information and programming for the
interface type the reader is connected to (for example: RS-
232, Keyboard Wedge, USB, etc.) and scan the appropriate
barcode to select your system’s correct interface type.
Interface Selection
Each reader model will support one of the following sets
of host interfaces:
General Purpose Models —
RS-232, RS-232 OPOS, USB, Key-
board Wedge, Wand.
Retail Point of Sale Models —
RS-232, RS-232 OPOS, USB,
IBM 46XX.
Information and programming options for each interface
type are provided in this section.
Configuring the Interface
Scan the programming barcode which selects the appro-
priate interface type matching the system the reader will
be connected to.
If you need to customize additional settings and features
associated with that interface, proceed to the correspond-
ing chapter in the Gryphon™ I PRG.
Unlike some other programming features and
options, interface selections require that you
scan only one programming barcode label. DO
NOT scan an ENTER/EXIT barcode prior to
scanning an interface selection barcode.
Some interfaces require the scanner to start in
the disabled state when powered up. If addi-
tional scanner configuration is desired while
in this state, pull the trigger and hold for 5
seconds. The scanner will change to a state
that allows programming with barcodes.
