Technical Specifications
Quick Reference Guide 33
Technical Specifications
The following table contains Physical and Performance
Characteristics, User Environment and Regulatory infor-
mation.
Item Description
Physical Characteristics
Color
White/Gray
Black/Gray
Dimensions
Height 7.1”/181 mm
Length 3.9”/100 mm
Width 2.8”/71 mm
Weight (without
cable)
Approximately
8.7 ounces/246 g (reader with display)
8.7 ounces/246 g (base charger)
Electrical Characteristics
Battery Type Li-Ion battery pack
Typical charge time
for full charge from
full discharge
4 hours with 12V external power supply
adapter
a
Max 22 hours with Host power
(in this case no supply adapter is needed)
a
Operating autonomy
(continuous reading)
30,000 reads
(typical)
Cradle consumption
and DC input supply
range
Volt 4.75-14 VDC; Power <8W
b
;
Imax 500mA when in host/bus powered
mode
b
.
Performance Characteristics
Light Source LEDs
Roll (Tilt) Tolerance ± 35° from normal
Pitch Tolerance ± 65°
