Introduction
16 Gryphon™ I GD4100/GM4100/GBT4100/L GD4300
Programming the Reader
Configuration Methods
Programming Barcodes
The reader is factory-configured with a standard set of default features. After scanning the
interface barcode, you can select other options and customize your reader through use of the
instructions and programming barcode labels available in the corresponding features section for
your interface. Customizable settings for many features are found in "Configuration Using
Barcodes" starting on page 37.
Some programming labels, like "Restore Custom Defaults"on page 34, require only the scan of
the single label to enact the change. Most, however, require the reader to be placed in
Progr
amming Mode prior to scanning them. Scan an ENTER/EXIT barcode once to enter
Programming Mode. Once the reader is in Programming Mode, scan a number of parameter
settings before scanning the ENTER/EXIT barcode a second time, which will then accept your
changes, exit Programming Mode and return the reader to normal operation.
There are some exceptions to the typical programming sequence described
above. Please read the description and setting instructions carefully when
configuring each programmable feature.
Datalogic Aladdin™
Datalogic Aladdin™ is a multi-platform utility program providing a quick and user-friendly
configuration method via the RS-232/USB-COM interface. Aladdin is available on the CD-
ROM provided with your product, and also from the Datalogic website. Aladdin allows you to
program the reader by selecting configuration commands through a user-friendly graphical
interface running on a PC. These commands are sent to the reader over the selected
communication interface, or they can be printed as barcodes to be scanned.
Aladdin also provides the ability to perform a software upgrade for th
e connected device (see the
Datalogic Aladdin™ Help On-Line for more details).
