Display Features ENTER/EXIT PROGRAMMING MODE

274

Gryphon™ I GD4100/GM4100/GBT4100/L GD4300

DISPLAY FEATURES

Contrast

Read the code until the desired contrast is reached.

Lighter

Darker

Font Size

DEFAULT

Font size = Small

$

Font size = Medium

$

Font size = Large
