Technical Specifications
332
Gryphon™ I GD4100/GM4100/GBT4100/L GD4300
Table 51
Programming Mode
- The following indications ONLY occur when the reader is in Programming Mode.
Label Program-
ming Mode Entry
A valid programming label has
been scanned.
LED blin
ks continuously
Reader sounds four low frequency
beeps
.
Label Program-
ming Mode Rejec-
tion of Label
A label has been rejected.
N/A
Reader sounds three times at low-
est frequency & current volume.
Label Program-
ming Mode Accep-
tance of Partial
La
bel
In cases
where multiple labels
mu
st be scanne
d to program one
feature, this indication acknowl-
edges each portion as it is success-
fully scanned.
N/A
Reader sounds one short beep at
highest frequency & cur
rent vol-
ume.
Label Program-
ming Mode Accep-
tance of
P
rog
ramming
Configuration option(s) have been
succ
essfully
programmed via
labels and the reader has exited
Programming Mode.
N/A
Reader sounds one high frequency
b
eep and 4 low frequency beeps
followed by reset beeps.
Label Program-
ming Mode Can-
cel Item Entry
Cancel label has been scanned.
N/A
Reader sounds two times at low
fr
equency and
current volume.
. Programming Mode Indications
Error Codes
Upon startup, if the reader sounds a long tone, this means the reader has not passed its
automatic Selftest and has entered FRU (Field Replaceable Unit) isolation mode. If the reader is
reset, the sequence will be repeated. The following table describes the LED flashes/beep codes
associated with an error found.
NUMBER OF LED
FLASHES/BEEPS
ERROR CORRECTIVE ACTION
1 Configuration
Contact Helpdesk for assistance
2 Interface PCB
4 Reader Module
5 Laser Pointer (if so equipped)
6 Digital PCB
14 CPLD/Code Mismatch
To Next Page
