Datalogic Magellan 1500i Quick Reference Guide

Quick Reference Guide i
Table of Contents
Quick Reference....................................................................1
Features ................................................................................1
Installation ............................................................................3
Optional Stand/Riser....................................................3
Removing the Stand/Bottom Cover ....................4
Magnetic Base Mounting .............................................4
How to Scan ..........................................................................5
Handheld Scanning Mode ............................................5
Center Zone Qualification.............................................6
Scanner Button..............................................................6
Scanner Button Functions ....................................6
LED and Beeper Indicators ..................................................8
Programming ......................................................................10
Service Port Mode ................................................10
Using Barcodes............................................................10
Interface Selection ......................................................11
Good Read Green Spot Duration................................12
Cell Phone Mode..........................................................13

Datalogic Magellan 1500i Specifications

General

Type	Fixed bar code reader
Sensor type	LED
Scanner type	2D
Yaw reading angle	-75 - 75 °
Scanner resolution	0.13 mm
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 86.1 lx
Linear (1D) barcodes supported	-
Optical sensor resolution (W x H)	1280 x 800 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, QR Code
Input voltage	5 V
Power consumption	500 mA
Power source type	USB
Buzzer	Yes
Certification	EN62471, IEC62471
Product color	Black
Housing material	Plastic
Image formats supported	BMP, JPEG
International Protection (IP) code	IP52
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
USB version	2.0
Connectivity technology	Wired
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	75 mm
Width	60 mm
Height	150 mm
Weight	240 g
