Datalogic Magellan 1500i Quick Reference Guide

6 Magellan™ 1500i
Center Zone Qualification
The configurable Center Zone can be set to limit the scan area to
allow Targeted Scanning of pick lists or other special items. Bar
codes will read in any orientation. The scanner will return to full
pattern Presentation Mode when set back down, after a configu-
rable time has elapsed.
Scanner Button
The Scanner Button performs multiple functions, depending on
how long it is pressed:
Scanner Button Functions
NOTE
The Scanner Button functions shown below are opera-
tional only when the Scanner is stationary. When in
Hand/Portable mode, the button acts as a trigger to
enable the reading of a barcode label.
PRESS
DURATION
FUNCTION COMMENT
Momentary
(when scanner is
asleep)
Wakes scanner from
Sleep Mode
Alternatively, the scanner can
be awakened by moving an
object through the scan zone.
Momentary
(when scanner is
awake)
Increments volume
Press the button momentar-
ily to increase speaker vol-
ume. When the loudest
volume is reached, a repeated
press of the button cycles
volume back to the lowest
setting, then volume
increases on subsequent
press(es). Five volume levels
are available.

Datalogic Magellan 1500i Specifications

General

Type	Fixed bar code reader
Sensor type	LED
Scanner type	2D
Yaw reading angle	-75 - 75 °
Scanner resolution	0.13 mm
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 86.1 lx
Linear (1D) barcodes supported	-
Optical sensor resolution (W x H)	1280 x 800 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, QR Code
Input voltage	5 V
Power consumption	500 mA
Power source type	USB
Buzzer	Yes
Certification	EN62471, IEC62471
Product color	Black
Housing material	Plastic
Image formats supported	BMP, JPEG
International Protection (IP) code	IP52
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
USB version	2.0
Connectivity technology	Wired
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	75 mm
Width	60 mm
Height	150 mm
Weight	240 g
