Installation
Route the interface cable from the terminal or host. Plug the AC
adapter (if one is used) into a wall outlet and the interface (I/F)
cable, then route and attach the I/F cable to the scanner. Verify
operation by presenting known-good bar codes to the scanner.
The unit should beep
1
and/or flash its good read LED and send
the bar code data to the host or terminal. If not, refer to the Trou-
bleshooting section of this guide.
Scanner installation is complete.
The Magellan 1500i uses intelligent illumination technology to
optimize light levels for a variety of bar code scanner functions
including automatic reading of bar codes from printed surfaces,
mobile devices and image capture in variable contrast environ-
ments.
Optional Stand/Riser
An optional stand / riser is available for the scanner. The stand
and riser have anti-skid pads on the bottom and can rest on any
desired horizontal surface or countertop. The scanner (along with
the stand/riser) can be easily repositioned on the counter or
lifted for portable use.
1. Beeper and LED behavior is selectable and may have been disabled by a previous
user.
A/C Adapter
(if needed)
To Host/Terminal
Connect
Here
I/F Cable
