8100/8100Ω and 8200/8200Ω Scanner
Scale Enforced Zero
Return
0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
Scale Interface Type
4 (RS-232
SASI)
4 (RS-232
SASI)
4 (RS-232
SASI)
7 (RS-232
single
cable)
1 (IBM
Port 17)
3
(IBM USB)
Scale Motion Level Fil-
ter
0 (low) 0 (low) 0 (low) 0 (low) 0 (low) 0 (low)
Scale LED Enable 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable)
Remote Display —
Enable/Disable
1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable)
EAS Active State
0 (active
low)
0 (active
low)
0 (active
low)
0 (active
low)
0 (active
low)
0 (active
low)
EAS Timeout 2 (20ms) 2 (20ms) 2 (20ms) 2 (20ms) 2 (20ms) 2 (20ms)
Aux Port Mode 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
Productivity Index
Reporting (PIR)
0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
Maximum Host-Trans-
mitted Message Length
0 (no limit) 0 (no limit) 0 (no limit) 0 (no limit) 0 (no limit) 0 (no limit)
Number of Host Trans-
mission Buffers
1
(2 buffers)
1
(2 buffers)
1
(2 buffers)
1
(2 buffers)
0
(1 buffer)
0
(1 buffer)
Global Prefix ("") ("") ("") ("")
Global Suffix
0D00
("\0D")
0D00
("\0D")
0D00("") ("")
IBM Scale Address 110
IBM Transmit Labels in
Code 39 Format
0 (disable)
IBM USB Scanner
Device Type
0 (fixed
scanner)
RS-232 Baud Rate 0 (19200) 1 (9600) 1 (9600) 1 (9600)
Aux RS-232
Wincor-
Nixdorf
Single
Cable
IBM 17 IBM USB
