Datalogic MAGELLAN 8200

Product Reference Guide E-3
RS-232 Number of Data
Bits
1 (8 data
bits)
1 (8 data
bits)
1 (8 data
bits)
0 (7 data
bits)
RS-232 Number of Stop
Bits
0 (1 stop
bit)
0 (1 stop
bit)
0 (1 stop
bit)
0 (1 stop
bit)
RS-232 Parity 0 (none) 0 (none) 2 (odd) 2 (odd)
RS-232 Hardware Con-
trol
0 (disable) 0 (disable)
1 (enable
CTS flow)
RS-232 Intercharacter
Delay
0 (none) 0 (none) 0 (none)
RS-232 Software Flow
Control
0 (disable) 0 (disable) 0 (disable) 0 (disable)
RS-232 Host Echo 0 (disable) 0 (disable)
RS-232 Host Echo
Quiet Interval
1 (10ms) 1 (10ms)
RS-232 Ignore Host
Commands
0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
RS-232 TTL
0 (normal
RS-232)
0 (normal
RS-232)
RS-232 TTL Invert 0 (disable) 0 (disable)
RS-232 Beep on ASCII
BEL
0 (disable) 0 (disable) 0 (disable)
RS-232 Beep After
Weigh
1 (enable) 1 (enable) 0 (disable) 1 (enable)
RS-232 Beep on Not on
File
1 (enable) 1 (enable) 1 (enable) 1 (enable)
RS-232 ACK NAK
Enable
0 (disable) 0 (disable) 0 (disable)
RS-232 ACK Character 6 (ACK) 6 (ACK) 6 (ACK)
RS-232 NAK Character 21 (NAK) 21 (NAK) 21 (NAK)
Aux RS-232
Wincor-
Nixdorf
Single
Cable
IBM 17 IBM USB
