8100/8100Ω and 8200/8200Ω Scanner
RS-232 Retry on ACK
NAK Timeout
1 (enable) 1 (enable) 1 (enable)
RS-232 ACK NAK Tim-
eout Value
1 (200ms) 1 (200ms) 1 (200ms)
RS-232 ACK NAK Retry
Count
3 resets 3 resets 3 resets
RS-232 ACK NAK Error
Handling
0 (ignore
errors)
0 (ignore
errors)
0 (ignore
errors)
RS-232 Label ID Con-
trol
1 (enable
as prefix)
1 (enable
as prefix)
1 (enable
as prefix)
1 (enable
as prefix)
Single Cable RS-232
Scanner Only Protocol
0 (scan-
ner-scale)
Single Cable RS-232
RTS CTS Selection
Option 5
Single Cable RS-232
Use BCC
0 (disable)
Single Cable RS-232
Use ACK/NAK
0 (disable)
Single Cable RS-232
Use STX
1 (enable)
Set Single Cable RS-
232 STX Character
83 (S)
Single Cable RS-232
Use ETX
1 (enable)
Set Single Cable RS-
232 ETX Character
13 (CR)
Single Cable RS-232
Datalogic Extensions
0 (std
protocol)
UPC-A Enable 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable)
Aux RS-232
Wincor-
Nixdorf
Single
Cable
IBM 17 IBM USB
