Datalogic MAGELLAN 8200

2-14 Magellan
®
8100/8100Ω and 8200/8200Ω Scanner
Refer to the appropriate drawing (Figure 2-7, Figure 2-8, or Figure 2-9)
for dimensional information concerning the model you’ll be installing.
Figure 2-7. Model 8100/8200 (Short Scanner) Cutout Dimensions
11.625"
(29.53cm)
Models 8100/8200
Dimensions
Models 8100/8200
Cutout
Models 8100/8200
Supports
Max. Radius = 0.25"
(0.635cm) 4x
4.125" ±.062 (10.5cm)
Liquid
Drainage
Liquid
Drainage
Support Rails
14.0"
(35.56cm)
12.9 lb.
(5.85kg)
Scanner
Weight
4.125" ±.062 (10.5cm)
11.1"
(28.19cm)
PLATTER
11.5"
(29.21cm)
SCANNER
5.1" (12.95cm)
8.57"
(21.77cm)
9.05"
(23.0cm)
PLATTER
13.88"
(35.26cm)
9.1"
(23.1cm)
Window
4.375"
(11.11cm)
5.3"
(13.46cm)
